| Brand | ILMVAC |
|---|---|
| Origin | Germany |
| Model | 2567C-50 |
| Pump Type | Oil-Free Reciprocating Piston Vacuum Pump |
| Pumping Speed | 4.9 m³/h (82 L/min) |
| Ultimate Vacuum | <80 mbar (abs) |
| Motor Power | 250 W |
| Dimensions (L×W×H) | 381×254×254 mm |
| Weight | 7.5 kg |
| Exhaust Port Diameter | 7 mm |
| Noise Level | ≤52 dB(A) |
| Duty Cycle | Continuous Operation Rated |
| Brand | ILMVAC |
|---|---|
| Origin | Germany |
| Pump Type | Oil-Free Diaphragm Pump |
| Model | 2546C-02 |
| Suction Rate | 2.3 m³/h (38.0 L/min) |
| Ultimate Vacuum | 80 mbar (abs) |
| Maximum Positive Pressure | 1 × 10⁶ Pa |
| Motor Power | 190 W |
| Dimensions (L×W×H) | 254 × 191 × 229 mm |
| Weight | 6.3 kg |
| Exhaust Port Diameter | 7 mm |
| Brand | ILMVAC |
|---|---|
| Origin | Germany |
| Model | MPC601T |
| Pump Type | Oil-Free Diaphragm Vacuum Pump |
| Ultimate Vacuum (Absolute) | <2 mbar |
| Pumping Speed | 4.5 m³/h (75 L/min) at 50 Hz |
| External Dimensions | 230 × 380 × 169 mm |
| Weight | 32.8 kg |
| Power Supply | 220 V, 50/60 Hz |
| Exhaust Port | DN16 KF Flange |
| Compliance | CE, RoHS, ISO 9001-certified manufacturing |
| Brand | ILMVAC |
|---|---|
| Origin | Germany |
| Pump Type | Hybrid (Rotary Vane + Chemically Resistant Diaphragm) |
| Model | P23Z-301 |
| Ultimate Vacuum | < 2 × 10⁻³ mbar |
| Pumping Speed | 21 m³/h |
| Motor Power | 900 W |
| Dimensions (W × D × H) | 590 × 345 × 420 mm |
| Weight | 46 kg |
| Oil Capacity | 1000 mL |
| Electrical Supply | 230 V, 50 Hz |
| Inlet Port | DN 25 KF |
| Brand | Vacuumer |
|---|---|
| Origin | South Korea |
| Pump Type | Oil-Lubricated Rotary Vane |
| Model | VOP 60 |
| Ultimate Vacuum Pressure | 6.7 × 10⁻² Pa (5 × 10⁻⁴ Torr) |
| Pumping Speed | 50 L/min (50 Hz) / 60 L/min (60 Hz) |
| Motor Power | 200 W, Single-Phase 220 V, 4-Pole |
| Motor Speed | 1430 RPM (50 Hz) / 1730 RPM (60 Hz) |
| Oil Capacity | 800 mL |
| Recommended Oil | COSMA-100 |
| Suction Port | NW25 (ISO-KF) |
| Operating Temperature Range | 7–40 °C |
| Dimensions (W × L × H) | 165 × 411 × 234 mm |
| Weight | 17 kg |
| Brand | ILMVAC |
|---|---|
| Origin | Germany |
| Model | MPC301Z |
| Pump Type | Oil-Free Diaphragm Vacuum Pump |
| Ultimate Vacuum (abs.) | < 8 mbar |
| Pumping Speed | 2.3 m³/h (38.0 L/min) |
| Dimensions (W×D×H) | 230 × 265 × 169 mm |
| Weight | 11.2 kg |
| Brand | ILMVAC |
|---|---|
| Origin | Germany |
| Model | MPC901Z |
| Pump Type | Oil-Free Diaphragm Vacuum Pump |
| Ultimate Vacuum (Absolute) | < 8 mbar |
| Pumping Speed (50 Hz) | 6.8 m³/h (113 L/min) |
| Exhaust Port Connection | 8 mm OD |
| Dimensions (W × D × H) | 230 × 380 × 169 mm |
| Weight | 32.8 kg |
| Motor Power | 100 W |
| Compliance | CE, RoHS, ISO 9001-certified manufacturing |
| Brand | ILMVAC |
|---|---|
| Origin | Germany |
| Model | P6Z-101 |
| Pump Type | Hybrid (Rotary Vane + Chemically Resistant Diaphragm) |
| Ultimate Vacuum | <2×10⁻³ mbar |
| Pumping Speed | 5.8 m³/h |
| Dimensions (W×D×H) | 500×330×340 mm |
| Weight | 25.5 kg |
| Motor Power | 400 W |
| Oil Capacity | 1000 mL |
| Electrical Supply | 230 V, 50 Hz |
| Inlet Port | DN 16 KF |
| Brand | Vacuumer |
|---|---|
| Origin | South Korea |
| Model | VOP 100 |
| Pump Type | Oil-Lubricated Rotary Vane |
| Pumping Speed (50/60 Hz) | 100 / 120 L/min |
| Ultimate Vacuum Pressure | 6.7 × 10⁻² Pa (6.7 × 10⁻¹ Pa with gas ballast engaged) |
| Motor | Single-phase 220 V, 400 W, 4-pole |
| Motor Speed (50/60 Hz) | 1430 / 1730 rpm |
| Recommended Oil | COSMA-100 |
| Oil Capacity | 900 mL |
| Suction Port | NW25 (ISO-KF) |
| Operating Temperature Range | 7–40 °C |
| Net Weight | 25 kg |
| Dimensions (W × L × H) | 171 × 464 × 238 mm |
| Brand | Vacuumer |
|---|---|
| Origin | South Korea |
| Pump Type | Oil-Lubricated Rotary Vane |
| Model | VOP 150 |
| Motor | Single-phase 220 V, 550 W, 4-pole |
| Speed (50/60 Hz) | 1430 / 1730 rpm |
| Pumping Speed | 170 / 200 L/min |
| Ultimate Vacuum Pressure | 6.7 × 10⁻² Pa (with gas ballast open: 6.7 × 10⁻¹ Pa) |
| Oil Capacity | 1000 mL |
| Recommended Oil | COSMA-100 |
| Suction Port | NW25 |
| Operating Temperature Range | 7–40 °C |
| Dimensions (W × L × H) | 189 × 504 × 253 mm |
| Weight | 28.5 kg |
| Built-in Features | Thermal overload protection, gas ballast valve, anti-backflow check valve, forced oil circulation cooling system |
| Brand | ILMVAC |
|---|---|
| Origin | Germany |
| Pump Type | Oil-Free Diaphragm Vacuum Pump |
| Ultimate Vacuum | <8 mbar (abs) |
| Pumping Speed | 1 m³/h (16.0 L/min) |
| Dimensions (W×D×H) | 195×235×145 mm |
| Weight | 6.5 kg |
| Brand | ILMVAC |
|---|---|
| Origin | Germany |
| Model | 2534C-02 |
| Pump Type | Oil-Free Reciprocating Piston Pump |
| Ultimate Vacuum (abs) | 93 mbar |
| Maximum Positive Pressure | 5 × 10⁵ Pa |
| Pumping Speed | 1.7 m³/h (28.0 L/min) |
| Motor Power | 93 W |
| Dimensions (L×W×H) | 206 × 224 × 254 mm |
| Weight | 5.3 kg |
| Exhaust Port Connection | 7 mm OD |
| Brand | ILMVAC |
|---|---|
| Origin | Germany |
| Pump Type | Oil-Free Reciprocating Piston Vacuum Pump |
| Model | 2562C-50 |
| Pumping Speed | 3.4 m³/h (56.7 L/min) |
| Ultimate Vacuum Pressure | 12 mbar (absolute) |
| Motor Power | 250 W |
| Dimensions (L×W×H) | 381 × 254 × 254 mm |
| Weight | 7.5 kg |
| Exhaust Port Diameter | 7 mm |
| Operating Mode | Dry Running |
| Vacuum/Pressure Display | Integrated Analog Gauge |
| Built-in Vacuum Regulator Valve | Yes |
| Buffer Bottle Included | Yes |
| Brand | ILMVAC |
|---|---|
| Origin | Germany |
| Model | P12Z-301 |
| Pump Type | Diaphragm–Rotary Vane Hybrid Vacuum Pump |
| Ultimate Vacuum | <2×10⁻³ mbar |
| Pumping Speed | 11 m³/h |
| External Dimensions (W×D×H) | 590 × 345 × 420 mm |
| Weight | 42.5 kg |
| Motor Power | 900 W |
| Oil Capacity | 1400 mL |
| Electrical Supply | 230 V, 50 Hz |
| Inlet Port | DN 25 KF |
| Oil-Lubricated Rotary Vane Stage | Yes |
| Chemical Resistance | Enhanced via Integrated Corrosion-Resistant Diaphragm Stage |
| Steam Tolerance | High |
| Safety Features | Integrated Pressure Relief Valve, Oil Aeration Bubble Device, Liquid–Gas Separation Bottle |
| Brand | ILMVAC |
|---|---|
| Origin | Germany |
| Model | PK 2 DC |
| Pump Type | Oil-Lubricated Dual-Stage Rotary Vane Pump |
| Ultimate Vacuum (Absolute) | < 1 × 10⁻² mbar |
| Pumping Speed | 1.8 m³/h (30 L/min) |
| Inlet/Outlet Port | DN 16 KF Flange |
| Weight | 8 kg |
| Power Supply | 50/60 Hz AC |
| Brand | Vacuumer |
|---|---|
| Origin | South Korea |
| Pump Type | Oil-Lubricated Rotary Vane |
| Model | VOP 200 |
| Ultimate Vacuum Pressure | 6.7 × 10⁻² Pa (6.7 × 10⁻¹ Pa with gas ballast enabled) |
| Pumping Speed | 220 L/min (50 Hz) / 260 L/min (60 Hz) |
| Motor | Single-phase 220 V, 550 W, 4-pole |
| Motor Speed | 1430 RPM (50 Hz) / 1730 RPM (60 Hz) |
| Recommended Oil | COSMA-100 |
| Oil Capacity | 1100 mL |
| Suction Port | NW25 (ISO-KF) |
| Operating Temperature Range | 7–40 °C |
| Dimensions (W × L × H) | 189 × 524 × 253 mm |
| Weight | 30 kg |
