| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | AXQ-5S |
| Instrument Type | Hot Mounting Press |
| Mounting Method | Hydraulic Auto-Pressure |
| Control System | Touchscreen Interface |
| Temperature Range | Ambient to 210 °C |
| Heating Power | 1300 W |
| Heating Time Adjustment | 0–99 min |
| Specimen Diameter Options | 25 mm / 30 mm / 40 mm / 50 mm (selectable) |
| Dimensions (W×D×H) | 360 mm × 400 mm × 550 mm |
| Power Supply | 220 V AC |
| Automation Features | Auto-pressure application & release, auto-specimen elevation, temperature-regulated heating, end-of-cycle automatic shutdown |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Model | MPD-2A |
| Speed Control | Infinitely Variable 50–1500 rpm + Preset Fixed-Speed Modes |
| Platen Diameter | φ230 mm (optional: φ200 / φ250 / φ300 mm) |
| Number of Platens | 2 |
| Dimensions (L×W×D) | 650 × 520 × 250 mm |
| Power Supply | 220 V AC |
| Motor Power | 550–750 W per platen |
| Drive System | Servo-Controlled Dual-Independent Drive |
| Rotation Direction | Bidirectional (Forward/Reverse selectable per platen) |
| Water Delivery | Adjustable Multi-Axis Spray Nozzle |
| Mounting Style | Benchtop |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | ZDP-300A |
| Control Interface | Touchscreen |
| Platen Diameter | 305 mm |
| Sample Diameter Range | 8–50 mm (customizable) |
| Polishing Feed Control | Programmable Auto-Dispensing (minimum interval: 0.1 s) |
| Motor Power | 1.5 kW |
| Frequency Regulation | Automatic |
| Voltage Regulation | Automatic |
| Input Power | 220 V AC |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Region of Origin | Domestic (China) |
| Model | QG-100Z |
| Instrument Type | Metallographic Cutting Machine |
| Spindle Speed | 2840 rpm |
| Max Cutting Diameter | 100 mm |
| Cutting Mode | Automatic/Manual |
| Cutting Table Dimensions | 300 × 280 mm |
| Cutting Feed Rate | 1–50 mm/min (infinitely variable) |
| Max Cutting Stroke | 280 mm (adjustable) |
| Feed Mechanism | Reciprocating (programmable) |
| Blade Specification | (300–350) × 2.0 × 32 mm |
| Cooling System | Automated 3-channel water cooling |
| Water Tank Capacity | 60 L |
| Motor Power | 4.0 kW |
| Configuration | Floor-standing integrated unit |
| Voltage Supply | 380 V AC |
| Weight | 300 kg |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | ZY-45 / ZY-65 |
| Instrument Type | Precision Cutting Machine |
| Cutting Method | Manual (optional pneumatic auto-feed) |
| Machine Configuration | Freestanding integrated unit |
| Worktable Type | Through-type |
| Max. Cutting Cross-section | 45 mm (ZY-45) / 65 mm (ZY-65) |
| Effective Cutting Depth | 100 mm |
| Worktable Dimensions | 650 × 300 mm (X-Y travel with lateral positioning) |
| Blade Specifications | Ø300–350 × 2–4 × 32 mm |
| Motor Power | 4 kW (ABB, ZY-45) / 7.5 kW (ABB, ZY-65) |
| Clamping Mechanism | Pneumatic |
| Door Actuation | Pneumatic |
| Cooling System | Automatic recirculating water cooling with magnetic chip separator |
| Coolant Tank Capacity | 60 L |
| Illumination | 24 V LED cold-light source |
| Power Supply | 380 V AC, 3-phase |
| Overall Dimensions | 1100 × 1200 × 1400 mm |
| Net Weight | 400 kg (ZY-45) / 500 kg (ZY-65) |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Region Classification | Domestic (China) |
| Model | BMP-1000 / BMP-2000 |
| Drive Speed | 100–1500 rpm (intelligent auto-adjustable) |
| Platen Diameter | 230 mm |
| Number of Platens | 1 (BMP-1000) / 2 (BMP-2000) |
| Specimen Capacity | 8 positions (with multi-specimen holder) |
| Pressure Application | Pneumatic (single-point or central loading) |
| Load Range | 1–40 N × 4 stations |
| Head Rotation Speed | 20–200 rpm |
| Polishing/Grinding Time | 0–9999 s |
| Motor Power | 550 W (AC variable-frequency drive) |
| Specimen Diameter | Standard 30 mm (custom diameters available) |
| Dimensions (BMP-2000/BMP-1000) | 650 × 650 × 700 mm / 450 × 650 × 700 mm |
| Voltage/Frequency | 220 V AC / 50 Hz |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic |
| Model | ZQ-50DWE |
| Instrument Type | Precision Cutting Machine |
| Display | 8-inch Color Touchscreen |
| Control System | PLC-based |
| Axes | X/Y/Z Three-Axis Motorized Positioning |
| Spindle Speed Range | 2000–12,000 rpm (Infinitely Variable) |
| X-Axis Travel | 70 mm |
| X-Axis Feed Speed | 0–200 mm/min (Infinitely Variable) |
| Z-Axis Stroke | 70 mm |
| Z-Axis Speed | 0–200 mm/min |
| Y-Axis Platform Travel | 200 mm |
| Y-Axis Speed | 0–200 mm/min |
| Max. Hollow Tube Diameter | Ø30 mm |
| Blade Dimensions | (100–200) × (0.3–1) × 25.4 mm |
| Cutting Feed Rate | 1–200 mm/min |
| Cooling System | Automated Recirculating Water Cooling |
| Water Tank Capacity | 40 L |
| Motor Power | 0.75 kW |
| Power Supply | 220 V AC |
| Net Weight | 100 kg |
| Cutting Modes | Vertical, Horizontal, Continuous, Coordinated Multi-Axis |
| Fixture Type | Dual-threaded Adjustable Clamp |
| Real-time Feed Tracking | Digital LCD Display |
| Reset Mode | Automatic Homing |
| Blade Feed Ratio | Programmable Feed/Retract Ratio |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | AXQ-2Q |
| Instrument Type | Hot Mounting Press |
| Mounting Method | Automated Hot Compression |
| Control System | Intelligent Digital Temperature & Time Controller |
| Pressure Actuation | Pneumatic |
| Sample Elevation | Motorized Auto-Lift |
| Heating Power | 800 W |
| Temperature Range | Ambient to 210 °C |
| Heating Timer | 0–99 min (adjustable) |
| Available Mold Diameters | Ø25 mm / Ø30 mm / Ø40 mm (user-selectable) |
| Dimensions (W×D×H) | 350 × 300 × 400 mm |
| Voltage | AC 220 V |
| Standard Accessories | Main Unit, One Set of Mounting Molds (integrated), 500 mL Thermosetting Resin (phenolic or epoxy-based), Technical Documentation (User Manual, Warranty Card, Certificate of Conformance) |
| Optional Accessory | External Air Compressor |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | ZXG-300 |
| Instrument Category | Metallographic Cutting Machine |
| Cutting Axis Speed | 200–1500 rpm |
| X-axis Stroke | 300 mm (motorized) |
| Y-axis Stroke | 300 mm (motorized) |
| X/Y Feed Speed | 0–100 mm/min (infinitely variable) |
| R-axis Rotation Speed | 1–100 rpm |
| Control System | 7-inch color touchscreen + PLC |
| Cutting Modes | Single-cut, intelligent block cutting, continuous slicing, R-axis rotational cutting |
| Effective Cutting Area | 300 × 300 mm |
| R-axis Range | 360° |
| Real-time Position Tracking | LCD digital display |
| Diamond Wire Diameter Options | 0.2, 0.25, 0.35, 0.5, 1.0 mm |
| Wire Feed Rate | 0–5 mm/min (infinitely variable) |
| Cooling System | Integrated liquid-based |
| Motor Power | 3.0 kW |
| Power Supply | 220 V AC |
| Weight | 800 kg |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | Q-3 |
| Instrument Category | Metallographic Cutting Machine |
| Maximum Cutting Diameter | 50 mm |
| Blade Specification | 250 × 1.5 × 32 mm |
| Cutting Method | Manual |
| Cooling System | Integrated Water Circulation System with 65 L Reservoir |
| Spindle Speed | 3500 rpm |
| Motor Power | 2.2 kW |
| Configuration | Benchtop |
| Power Supply | 380 V AC, 3-phase |
| Net Weight | 150 kg |
| Standard Accessories | Main Unit (1), Precision Cutting Blades (2 pcs), Tool Kit (1 set) |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | AXQ-100 |
| Instrument Type | Hot Mounting Press |
| Sample Diameter Options | Φ25 mm, Φ30 mm, Φ40 mm, Φ45 mm |
| Heating Power | 2 × 1000 W |
| Temperature Range | 0–300 °C |
| Pressure Range | 0–2 MPa (applied pressure) |
| Curing Time | 0–99 min (adjustable) |
| Cooling Time | 0–99 min (adjustable) |
| Air Supply Requirement | 0.5–0.8 MPa |
| Cooling Method | Automated Recirculating Water Cooling |
| Control System | PLC with Color Touchscreen Interface |
| Machine Configuration | Floor-standing, Dual-Station, Fully Automatic Cycle |
| Dimensions (W×D×H) | 700 × 560 × 1250 mm |
| Weight | 100 kg |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | ZQ-150F |
| Instrument Type | Metallographic Cutting Machine |
| Spindle Speed | 100–3000 rpm (infinitely variable) |
| X-Axis Travel | 50 mm (motorized) |
| X-Axis Feed Speed | 0–100 mm/min (infinitely variable) |
| Z-Axis Cutting Stroke | 150 mm |
| Z-Axis Feed Speed | 0–200 mm/min |
| Y-Axis Travel | 300 mm (motorized) |
| Y-Axis Feed Speed | 0–300 mm/min |
| Max. Specimen Dimensions | Ø120 mm or 400 × 200 × 110 mm |
| Cutting Wheel Size | (250–350) × (2–3) × 32 mm |
| Clamping Platform | Split-type dual-layer movable stage |
| Cutting Table Size | 400 × 300 mm |
| Feed Rate Control | 1–200 mm/min (real-time adjustable) |
| Effective Cutting Distance | 150 + 250 mm |
| Cooling System | Dual-channel water cooling with multi-nozzle spray |
| Water Tank Capacity | 150 L |
| Motor Power | 4 kW (ABB) |
| Power Supply | 380 V AC |
| Machine Weight | 500 kg |
| Control System | 8-inch color touchscreen + Mitsubishi PLC |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | QG-300 |
| Instrument Type | Metallographic Cutting Machine |
| Spindle Speed | 2840 rpm |
| X-Axis Platform Travel | 70 mm |
| Y-Axis Spindle Stroke | 200 mm |
| Z-Axis Cutting Stroke | 100 mm |
| Max. Cutting Cross-Section | 200 × 140 mm |
| Max. Cutting Diameter | 150 mm |
| Cutting Method | Manual Three-Axis Control |
| Effective Feed Distance | 250 + 100 mm |
| Cutting Table Dimensions | 400 × 400 mm |
| Blade Specifications | (350–450) × (2.0–4.0) × 32 mm |
| Clamping Stage | Split-Type Dual-Layer Movable Precision Positioning Platform |
| Cooling System | Automatic 4-Channel Water Cooling |
| Water Tank Capacity | 150 L |
| Motor Power | 5.5 kW |
| Machine Configuration | Floor-Standing Integrated Design |
| Power Supply | 380 V AC |
| Weight | 550 kg |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | QG-1 |
| Instrument Type | Metallographic Cutting Machine |
| Max Cutting Cross-Section | Ø50 × 50 mm |
| Motor Power | 1.1 kW / 380 V, 50 Hz |
| Grinding Wheel Specification | Ø300 × Ø32 × 2.0 mm |
| Overall Dimensions | 580 × 560 × 680 mm |
| Spindle Speed | 2800 rpm |
| Net Weight | 60 kg |
| Optional Accessory | Quick-Release Sample Clamp |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-made) |
| Model | ZY-300Z |
| Instrument Type | Precision Cutting Machine |
| Spindle Speed | 100–3000 rpm (infinitely variable) |
| Vertical Cutting Stroke | 0–150 mm |
| Cutting Feed Rate | 0–100 mm/min |
| Control System | 8-inch color touchscreen + Mitsubishi PLC |
| Clamping Method | Hydraulic auto-clamping |
| Maximum Workpiece Cross-section | 75 × 75 mm (linear guides) |
| Cutting Orientation | Vertical |
| Position Feedback | Real-time digital display of cut completion |
| Platform Dimensions | 800 × 400 mm (fixed) |
| Blade Specifications | Ø300–400 × 2–4 × 32 mm |
| Cooling System | Closed-loop water cooling with magnetic chip separator |
| Coolant Tank Capacity | 250 L |
| Motor | 7.5 kW ABB motor |
| Machine Configuration | Floor-standing integrated unit |
| Power Supply | 380 V AC, 3-phase |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Model | ZMP-2000Z |
| Rotational Speed | 50–1500 rpm |
| Platen Diameter | 230 mm |
| Number of Platens | 2 |
| Dimensions (L×W×D) | 870 mm × 800 mm × 700 mm |
| Applied Pressure | Center Load 300 N |
| Air Supply Requirement | 0.5–0.9 MPa |
| Control System | PLC with 8-inch Color Touchscreen |
| Sample Capacity | 8 positions (6 × Ø30 mm + 2 × Ø40 mm) |
| Motor Power | 2 × 750 W servo motors (torque: 2.39 N·m each) |
| Grinding/Polishing Time Range | 0–9999 s per stage (dual-stage programmable) |
| Abrasive Dispensing | Dual-channel automated spray system |
| minimum dispensing interval & duration | 0.1 s |
| Storage Capacity | Up to 100 user-defined grinding-polishing protocols |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Region of Origin | Domestic (China) |
| Model | ZQ-540E |
| Instrument Type | Precision Cutting Machine |
| Spindle Speed | 1000–12000 rpm (infinitely variable) |
| Y-Axis Travel | 200 mm |
| Y-Axis Movement | Motorized |
| Max. Cutting Diameter | 40 mm |
| Cutting Orientation | Horizontal |
| Blade Dimensions | (100–200) × (0.3–0.5) × 25.4 mm |
| Cooling Method | Automated Recirculating Water Cooling |
| Water Tank Capacity | 40 L |
| Motor Power | 0.75 kW |
| Power Supply | 220 V AC |
| Approx. Weight | 60 kg |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | QG-100X |
| Instrument Category | Metallographic Cutting Machine |
| Spindle Speed | 2840 rpm |
| X-Axis Platform Travel | 50 mm |
| Y-Axis Platform Travel | 250 mm (Manual) |
| Max Cutting Dimension | 380 × 130 × 100 mm |
| Effective Feed Distance | 220 mm |
| Cutting Table Dimensions | 310 × 250 mm |
| Blade Specification | (300–350) × 2.0 × 32 mm |
| Clamping Stage | Split-type Dual-layer Movable Platform |
| Cooling System | Automatic 4-Channel Water Cooling |
| Water Tank Capacity | 80 L |
| Motor Power | 4.0 kW |
| Machine Configuration | Floor-standing Integrated Unit |
| Power Supply | 380 V AC |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | MPD-1J |
| Speed Control | Infinitely Variable 50–1500 rpm + Preset Speed Steps |
| Platen Diameter | Ø230 mm (optional: Ø200 / Ø250 / Ø300 mm) |
| Number of Platens | 1 |
| Dimensions (L×W×D) | 340 × 520 × 250 mm |
| Motor Power | 750 W |
| Rotation Direction | Bidirectional (Forward/Reverse) |
| Water Nozzle | Adjustable Swivel Spray |
| Voltage | 220 V AC |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | YR-100ES |
| Instrument Category | Metallographic Cutting Machine |
| Cutting Axis Speed | 200–1500 rpm |
| X-Axis Stroke | 100 mm (motorized) |
| Y-Axis Stroke | 100 mm (motorized) |
| X/Y Feed Speed | 0–100 mm/min (infinitely variable) |
| R-Axis Rotation Speed | 1–100 rpm |
| Control System | 7-inch color touchscreen + PLC |
| Cutting Modes | Single-cut, intelligent block cutting, continuous slicing, R-axis rotational cutting |
| Feed Mechanism | Motorized |
| Effective Cutting Range | 100 × 100 mm (X/Y), 360° R-axis rotation |
| Real-time Digital Display | Yes |
| Cutting Table Dimensions | 300 × 240 mm |
| Diamond Wire Diameter Options | 0.20, 0.25, 0.35, 0.50 mm |
| Wire Feed Rate | 0–5 mm/min (infinitely variable) |
| Reset Function | Automatic (with completion tracking) |
| Coolant System | Integrated 30 L reservoir |
| Motor Power | 1.0 kW |
| Power Supply | 220 V AC |
| Net Weight | 200 kg |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | ZQ-30D |
| Instrument Type | Precision Cutting Machine |
| Spindle Speed | 200–3000 rpm (infinitely variable) |
| X-Axis Travel (Manual) | 50 mm |
| Y-Axis Travel (Automatic) | 100 mm |
| Max. Cutting Diameter | 30 mm |
| Feed Rate | 1–200 mm/min (adjustable in real time) |
| Effective Cutting Depth | 70 mm |
| Cutting Table Dimensions | 150 × 100 mm |
| Blade Specifications | Ø150–180 mm × Thickness 0.3–1 mm × Arbor 25.4 mm |
| Cooling System | Recirculating Chilled Water (40 L reservoir) |
| Motor Power | 750 W |
| Power Supply | 220 V AC |
| Control System | Color Touchscreen + PLC-Based Controller |
| Real-Time Feed Monitoring | LCD Digital Display with Auto-Reset Function |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | ZQ-100 |
| Instrument Type | Metallographic Cutting Machine |
| Main Motor Power | 4.0 kW (ABB) |
| Maximum Cutting Dimensions | 380 × 130 × 100 mm |
| Cutting Wheel Specifications | Ø300–350 × 2.0 × Ø32 mm |
| Coolant Tank Capacity | 90 L |
| Weight | 330 kg |
| Control System | PLC + Full-Color Touchscreen HMI |
| Feed Mode | Three-Forward-One-Back (Adjustable Ratio) |
| Feed Speed | 1–25 mm/min (Continuously Variable, Up to 60 mm/min Peak) |
| X-Axis Travel | 50 mm (Motorized on ZQ-100A/C |
| Y-Axis Travel | 280 mm (Motorized/Manual Selectable) |
| Y-Axis Speed | 0–60 mm/min (CV) |
| X-Axis Speed | 0–100 mm/min (CV) |
| Spindle Speed | 2840 rpm (ZQ-100/ZQ-100C) |
| Cutting Table Size | 310 × 310 mm |
| Precision Positioning Platform | Split-Type Dual-Layer Movable Stage |
| Coolant Delivery | Triple-Channel Automated Water Cooling |
| Feed Distance Range | 0–200 mm (Programmable) |
| Reset Function | Fully Automatic Return-to-Home |
| Display | Real-Time LCD Feed Tracking & Process Monitoring |
| Enclosure Finish | Powder-Coated Steel Cabinet |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Equipment Type | Fully Automatic Metallographic Cutting Machine |
| Model | ZQ-600Z |
| Cutting Axes | 3-Axis (X/Y/Z) Simultaneous Control |
| Cutting Modes | Vertical, Layered, Horizontal, Reciprocating |
| Chamber Design | Through-Type Open Architecture with Full-View Transparent Observation Window |
| Chip Separation | Integrated Magnetic Separation System for Metallic Debris Removal |
| Application Focus | Precision Sampling of Automotive Components, Castings, and Irregular/Long Specimens |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | Q-2 |
| Instrument Type | Manual Metallographic Cutting Machine |
| Maximum Cutting Diameter | 35 mm |
| Cutting Wheel Dimensions | 250 × 1.5 × 32 mm |
| Spindle Speed | 2800 rpm |
| Motor Power | 1.1 kW |
| Mounting Style | Benchtop |
| Power Supply | 380 V AC |
| Net Weight | 60 kg |
| Standard Configuration | Main Unit (1), Precision Cutting Wheels (2 pcs), Tool Kit (1 set) |
Show next
