| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Product Category | Domestic |
| Model | BI-13 Biological Inverted Microscope |
| Instrument Type | Inverted Microscope |
| Eyepiece | Wide-Field WF10X (Φ18 mm) |
| Objective Lenses | Achromatic 4X/0.10, 10X/0.25, 40X/0.65 (spring-loaded), 100X/1.25 (spring-loaded, oil immersion) |
| Magnification Range | 40X–1000X (standard) |
| Focusing Mechanism | Coaxial or separate coarse/fine focus |
| fine focus graduation | 4 µm |
| Stage | Dual-layer mechanical stage (125 mm × 115 mm) |
| travel range | 70 mm × 30 mm |
| Condenser | Abbe condenser, N.A. 1.25, height-adjustable |
| Illumination | 20 W tungsten-halogen lamp, dual-voltage (110 V / 220 V, 50/60 Hz) |
| Optional Light Sources | 5 W fluorescent lamp |
| Optional Accessories | WF16X eyepiece, pointer eyepiece, 3-position turret, green/yellow filters, plano-concave mirror with stand, USB/VIDEO photo-eyepiece |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-Made) |
| Model | BID-300 Inverted Biological Microscope |
| Instrument Type | Inverted Microscope |
| Eyepiece Configuration | Binocular |
| Optical Magnification Range | 100×–400× |
| Objective Conjugate Distance | Infinity |
| Eyepiece Port Diameter | 30 mm |
| Parfocal Distance | 10 mm |
| Eyepieces | Wide-Field WF10X (Φ22 mm), Centering Telescope |
| Infinity-Corrected Long Working Distance Achromatic Objectives (Cover Glass Thickness | 1.2 mm): 10X/0.25 (WD 19.4 mm), 20X/0.40 (WD 8.0 mm), 40X/0.60 (WD 3.5 mm) |
| Infinity-Corrected Phase Contrast Objectives (PHP) | 10X/0.25 (WD 4.3 mm) |
| Eyepiece Tube | Trinocular, 45° Inclination, Interpupillary Adjustment 53–75 mm |
| Focus Mechanism | Coaxial Coarse/Fine Focus with Adjustable Coarse Tension, Locking Mechanism, Limit Stop, Fine Focus Graduation: 2 µm |
| Nosepiece | Quintuple (5-Position) |
| Stage | Dual-Layer Mechanical Stage (227 × 208 mm), Travel Range: 134.5 × 77 mm, Removable Vernier Scale |
| Stage Plate | Circular Glass Plate (Φ118 mm) |
| Culture Dish Adapters | Three Interchangeable Plates — Type I (86 × 129.5 mm, fits Φ87.5 mm dish), Type II (34 × 77.5 mm, fits Φ68.5 mm dish), Type III (57 × 82 mm) |
| Condenser | Long Working Distance Condenser (WD 55 mm) with Rotating Phase Contrast Annulus Disc |
| Illumination | 6 V / 30 W Halogen Lamp, Adjustable Brightness and Height |
| Filters | Blue, Green, Ground Glass |
| Optional Accessories | Graticule Eyepiece (10X, 0.1 mm/div), Additional Phase Contrast Objectives (20X/0.40 PHP2, 40X/0.65 PHP2), Multi-Format Sample Holders (for 35 mm, 50 mm, T25, 66 × 66 mm square, and Standard Slide), Yellow Filter, Extended WD Condenser (WD 70 mm), Rotating Phase Contrast Disc |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-Made) |
| Model | BI-16 Biological Inverted Microscope |
| Instrument Type | Inverted Microscope |
| Eyepiece Configuration | Binocular |
| Magnification Range | 40×–1600× |
| Eyepieces | Wide-Field WF10× (Φ18 mm), WF16× (Φ11 mm) |
| Achromatic Objectives | 4×/0.10, 10×/0.25, 40×/0.65 (spring-loaded), 100×/1.25 (spring-loaded, oil immersion) |
| Nosepiece | Four-position, outward-facing ball-bearing centering turret |
| Stage | Dual-layer mechanical stage (135 mm × 125 mm) |
| Condenser | Abbe condenser, N.A. 1.25, vertically adjustable |
| Filters | Blue filter, ground glass |
| Illuminator | 6 V / 20 W halogen lamp with brightness control |
| Focusing Mechanism | Coaxial coarse/fine focus |
| fine focus graduation | 2 µm |
| Optional Configurations | Phase contrast (PH-I/PH-II turret, PHP objectives), LED illumination (9 V/500 mA adapters), polarizing system (360° rotatable polarizer, slide-in analyzer), infinity-corrected optical pathway, USB/VIDEO camera eyepiece |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-Made) |
| Model | XSP-8CA Trinocular Biological Microscope |
| Microscope Type | Upright Biological Microscope |
| Optical Configuration | Trinocular Head (30° Inclined, Interpupillary Adjustment 55–75 mm) |
| Eyepieces | Widefield WF10×/18 mm (Standard), Optional: WF16×, WF20×, P16× |
| Objective Lenses | Achromatic 4×, 10×, 40× (spring-loaded), 100× (spring-loaded, oil immersion) |
| Mechanical Stage | Dual-layer, 160 mm × 140 mm platform, 80 mm × 50 mm travel range |
| Condenser | NA 1.25 Abbe condenser with adjustable iris diaphragm and filter holder |
| Focus Mechanism | Coaxial coarse/fine focus |
| fine focus graduation | 2 µm per division |
| Illumination | 6 V / 20 W halogen lamp, AC 220 V / 110 V compatible, brightness continuously adjustable, Köhler illumination capable |
| Optional Accessories | Darkfield & phase contrast kits, teaching head, mirror, camera adapters (for DSLR/CCD), image measurement software, semi-plan and plan apochromatic objective sets (20×, 60×, oil-immersion variants) |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-made) |
| Model | BI-25 |
| Instrument Type | Inverted Microscope |
| Eyepiece Configuration | Binocular |
| Magnification Range | 40×–1000× |
| Objective Lens System | Infinity-Corrected Achromatic Plan Objectives (4×/0.10, 10×/0.25, 40×/0.65 spring-loaded, 100×/1.25 oil immersion spring-loaded) |
| Eyepieces | Widefield WF10× (Φ22 mm) |
| Interpupillary Adjustment | Binocular tube inclined at 30° |
| Focusing Mechanism | Coaxial coarse/fine focus with adjustable tension, locking mechanism, and limit stop |
| fine focus graduation | 2 µm |
| Nosepiece | Four-position inward-rolling ball bearing turret with positive positioning |
| Stage | Dual-layer mechanical stage (210 mm × 140 mm), travel range 75 mm × 50 mm |
| Condenser | Abbe condenser (N.A. 1.25), vertically adjustable |
| Illumination | 6 V / 30 W halogen lamp with continuous intensity control |
| Built-in Field Diaphragm | Integrated in collector lens |
| Filter Holder | Includes blue filter and ground glass diffuser |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-made) |
| Model | BID-500 Inverted Biological Microscope |
| Instrument Type | Inverted Microscope |
| Eyepiece Configuration | Binocular |
| Optical Magnification | 100×–400× |
| Mechanical Tube Length | ∞ |
| Object Distance (Conjugate) | ∞ |
| Eyepieces | Widefield WF10X (Φ22 mm), Centering Eyepieces |
| Interpupillary Adjustment Range | 48–75 mm |
| Eyepiece Inclination | 45° |
| Eye Point Height | 400 mm above stage |
| Eyepiece Port Diameter | Φ30 mm |
| Parfocal Distance | 10 mm |
| Brightfield Objectives (Cover Slip Thickness | 1.2 mm): 10×/0.25 (WD 4.27 mm), 20×/0.4 (WD 8.0 mm), 40×/0.6 (WD 3.5 mm) |
| Phase Contrast Objectives (PHP2, Cover Slip Thickness | 1.2 mm): 10×/0.25 (WD 4.27 mm) |
| Nosepiece | Quintuple Revolving Nosepiece |
| Focus Mechanism | Coaxial Coarse/Fine Focus, Fine Focus Graduation: 2 µm, Adjustable Coarse Focus Tension, Locking & Limit Stop Functions, Total Focusing Travel: 11 mm |
| Long Working Distance Condenser | WD 70 mm, Integrated Slider-Type Phase Contrast Module |
| Stage Dimensions | 224 × 208 mm, Travel Range: 112 × 79 mm, Removable Scale Plate |
| Petri Dish Carriers | Three Interchangeable Plates — Type I: 86 × 129.5 mm (fits Ø87.5 mm dishes), Type II: 34 × 77.5 mm (fits Ø68.5 mm dishes), Type III: 57 × 82 mm |
| Phase Contrast System | Sliding Phase Annulus Condenser with Centering Adjustment |
| Illumination | 9 W LED, Continuously Variable Intensity Control |
| Filters | Ground Glass Diffuser, Blue Filter |
| Calibration Tools Included | M4 and M5 Hex Keys |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-made) |
| Model | BID-200 Inverted Biological Microscope |
| Microscope Type | Inverted Microscope |
| Eyepiece Configuration | Binocular |
| Optical Magnification Range | 100×–400× |
| Mechanical Tube Length | 160 mm |
| Object Distance (Conjugate) | 195 mm |
| Eyepiece Port Diameter | 23.2 mm |
| Parfocal Distance | 10 mm |
| Standard Eyepiece | Wide-Field WF10× (Φ20 mm) |
| Objective Lenses | Long Working Distance Plan Achromatic PLL: 10×/0.25 (WD 8.8 mm), 25×/0.40 (WD 4.8 mm), 40×/0.60 (WD 3.3 mm) |
| Phase Contrast Objectives | PLL 10×/0.25 PHP2 |
| Trinocular Head | 30° Inclined, 100% Light Path for Imaging, Interpupillary Adjustment 53–75 mm |
| Focus Mechanism | Coaxial Coarse/Fine Focus with Adjustable Coarse Tension, Locking & Upper/Lower Limit Stops, Fine Focus Graduation: 2 µm |
| Nosepiece | 4-Position Revolving (Ball-Bearing Centered) |
| Stage | Dual-Layer Mechanical Stage (224 × 208 mm), Travel Range 130 × 79 mm, Removable Vernier Scale |
| Specimen Holders | Three Configurations — (1) 77.5 × 34 mm (for Ø68.5 mm round dishes), (2) 82 × 57 mm culture vessel support, (3) 129.5 × 86 mm (for Ø87.5 mm round dishes) |
| Transmitted Illumination | 6 V / 30 W Halogen Lamp with Continuous Brightness Control |
| Filters | Blue, Green, Ground Glass |
| Phase Contrast Assembly | Sliding-Type Annular Diaphragm System with Centering Telescope, 10× Phase Ring Plate, Adjustable Condenser (NA 0.4, WD 50 mm) |
| Condenser | NA 0.4, WD 55 mm, Integrated Phase Contrast Capability |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-made) |
| Model | BI-21 Biological Microscope |
| Microscope Type | Inverted Microscope |
| Eyepiece Configuration | Binocular |
| Magnification Range | 40×–1000× |
| Eyepieces | Widefield WF10× (Φ20 mm) |
| Objective Lenses | Achromatic (BI-21A: 4×/0.10, 10×/0.25, 40×/0.65 spring, 100×/1.25 spring/oil) |
| Semi-Plan Achromatic (BI-21B | 4×/0.10, 10×/0.25, 20×/0.40, 40×/0.65 spring, 100×/1.25 spring/oil) |
| Nosepiece | BI-21A – 4-position inward ball-bearing turret |
| Stage | Dual-layer mechanical stage (160 mm × 140 mm), travel range 75 mm × 50 mm |
| Condenser | Abbe condenser, N.A. 1.25, vertically adjustable |
| Illumination | 6 V / 20 W halogen lamp with brightness control, integrated field diaphragm and collector |
| Focus Mechanism | Coaxial coarse/fine focus with adjustable coarse tension, locking mechanism, limit stop, fine focus graduation: 2 µm |
| Optical Design | Finite-conjugate (standard) |
| Optional Accessories | Phase contrast kits (PH-I/PH-II turret, PHP objectives), LED illumination upgrade (9 V / 500 mA adapters), polarizing system (360° rotatable polarizer, push-pull analyzer), darkfield condensers (dry/wet), plan achromat objectives (up to 60×/0.85), USB/VIDEO trinocular photo-tube |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-made) |
| Model | BI-22 Biological Inverted Microscope |
| Instrument Type | Inverted Microscope |
| Eyepiece Configuration | Binocular |
| Magnification Range | 40×–1000× |
| Eyepieces | Wide-field WF10× (Φ20 mm) |
| Objectives | Plan Achromatic 4×/0.10, 10×/0.25, 20×/0.40, 40×/0.65 (spring-loaded), 100×/1.25 (spring-loaded, oil immersion) |
| Interpupillary Adjustment | Adjustable binocular head, inclined at 30° |
| Focusing Mechanism | Coaxial coarse/fine focus with adjustable coarse tension, locking mechanism, and limit stop |
| fine focus graduation | 2 µm |
| Nosepiece | Quintuple revolving nosepiece with inward ball-bearing centering |
| Stage | Dual-layer mechanical stage (160 mm × 140 mm), travel range: 75 mm × 50 mm |
| Condenser | Abbe condenser, N.A. 1.25, vertically adjustable |
| Illumination | 12 V / 20 W halogen lamp with brightness control |
| Filters | Blue filter and ground glass |
| Collector | Halogen-compatible collector |
| Optional Accessories | Phase contrast kits (PH-I/PH-II condensers, PHP objectives), LED power adapters (9 V / 500 mA, 110 V or 230 V input), polarizing system (360° rotatable polarizer, push-pull analyzer), infinity-corrected optical pathway components, USB/VIDEO trinocular phototube |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | BI-14 Biological Microscope |
| Microscope Type | Inverted Microscope |
| Eyepiece Configuration | Binocular |
| Magnification Range (Standard) | 40×–1000× |
| Max Optional Magnification | 64×–1600× |
| Eyepieces | Widefield WF10× (Φ18 mm) |
| Objectives | Achromatic 4×/0.10, 10×/0.25, 40×/0.65 (spring-loaded), 100×/1.25 (spring-loaded, oil immersion) |
| Nosepiece | Four-position inward-rolling ball bearing turret with external positioning |
| Stage | Dual-layer mechanical stage (125 mm × 115 mm), travel range 70 mm × 30 mm |
| Condenser | Abbe condenser with adjustable iris diaphragm and filter holder, NA 1.25, vertically adjustable |
| Filters | Blue filter, ground glass |
| Illuminator | 6 V / 15 W halogen lamp with brightness control |
| Fine Focus Increment | 4 µm |
| Focus Mechanism | Coaxial coarse/fine focusing (BI-14A: standard |
| BI-14B | with limit lock, tension adjustment, and locking mechanism) |
| Tube Angle | 30° inclined, sliding binocular head |
| Optional Accessories | WF16× eyepieces, reticle eyepieces, monocular tube (45°), three-position turret, rotary or fixed stage variants, green/yellow filters, 5 W fluorescent lamp (110/220 V), high-intensity white LED illuminator, plano-concave mirror with stand, incandescent lamp, LED power adapters (9 V / 500 mA), USB/VIDEO trinocular photo-port, simple polarizing system (360° rotatable polarizer + push-pull analyzer) |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-Made) |
| Model | BI-15 Biological Inverted Microscope |
| Instrument Type | Inverted Microscope |
| Eyepiece Configuration | Binocular Head (30° Inclination) |
| Magnification Range | 40×–1000× (Optional Extended Range: 64×–1600×) |
| Eyepieces | Wide-Field WF10× (Φ18 mm) |
| Objectives | Achromatic 4×/0.10, 10×/0.25, 40×/0.65 (Spring), 100×/1.25 (Spring, Oil Immersion) |
| Focusing Mechanism | Coaxial Coarse/Fine Focus (BI-15A/C: Limit Stop |
| BI-15B/D | Lockable + Adjustable Coarse Tension |
| Fine Focus Graduation | 4 µm) |
| Nosepiece | 4-Position (BI-15A/B: Outward Ball-Bearing |
| BI-15C/D | Inward Ball-Bearing) |
| Stage | Dual-Layer Mechanical Stage (125 mm × 115 mm) |
| Travel Range | 70 mm × 30 mm |
| Condenser | Abbe Condenser (N.A. 1.25), Adjustable Height, with Iris Diaphragm & Filter Holder |
| Filters | Blue Filter, Ground Glass |
| Illuminator | 12 V / 20 W Halogen Lamp, Continuously Variable Brightness Control |
| Optional Accessories | WF16× Eyepieces, Reticle Eyepieces, Monocular or Push-Pull Binocular Tubes, 3-Position Nosepiece, Movable Scale Stage, Green/Yellow Filters, 5 W Fluorescent Lamp, High-Intensity White LED Illuminator, Mirror Assembly, AC Input LED Power Adapters (9 V / 500 mA), USB/VIDEO Trinocular Photo-Adapter, Basic Polarization Kit (360° Rotatable Polarizer + Sliding Analyzer) |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-Made) |
| Model | BI-19 Biological Inverted Microscope |
| Instrument Type | Inverted Microscope |
| Eyepiece Configuration | Binocular |
| Magnification Range | 40×–1000× |
| Eyepieces | Wide-Field WF10× (Φ18 mm) |
| Objectives | Achromatic BI-19A or Semi-Plan Achromatic BI-19B (4×/0.10, 10×/0.25, 40×/0.65 spring-loaded, 100×/1.25 spring-loaded oil-immersion) |
| Interpupillary Adjustment | 55–75 mm |
| Inclined Binocular Tube | 30° tilt |
| Focusing Mechanism | Coaxial coarse/fine focus with adjustable coarse tension, locking knob, and limit stop |
| fine focus graduation | 2 µm |
| Nosepiece | Four-position outward-rolling ball bearing turret with centering mechanism |
| Stage | Dual-layer mechanical stage (135 mm × 125 mm), travel range 75 mm × 35 mm |
| Condenser | Abbe condenser, N.A. 1.25, vertically adjustable |
| Filters | Blue filter, ground glass |
| Illuminator | 6 V / 20 W halogen lamp with brightness control |
| Optional Configurations | Phase contrast (PH-I/PH-II turret, PHP objectives), LED illumination upgrade, polarizing accessories, USB/VIDEO camera adapters, infinite-corrected optical path components, darkfield condensers (dry/wet), extended objective sets (5×, 20×, 60×), reticle eyepieces, teaching twin-head tube |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Product Category | Domestic |
| Model | BID-100 Inverted Phase Contrast Biological Microscope |
| Instrument Type | Inverted Microscope |
| Eyepiece Configuration | Binocular |
| Optical Magnification Range | 100×–400× |
| Mechanical Tube Length | 160 mm |
| Object Conjugate Distance | 195 mm |
| Eyepiece Port Diameter | 23.2 mm |
| Parfocal Distance | 10 mm |
| Eyepieces | Wide-Field WF10× (Φ20 mm), Centering Telescope |
| Long Working Distance Plan Achromatic Objective PLL (Cover Glass Thickness | 1.2 mm): 10×/0.25 (WD 8.8 mm), 25×/0.40 (WD 4.8 mm), 40×/0.60 (WD 3.3 mm) |
| Long Working Distance Plan Achromatic Phase Contrast Objective PHP (Cover Glass Thickness | 1.2 mm): 10×/0.25 (WD 8.8 mm) |
| Trinocular Head | 30° Inclination, Interpupillary Adjustment Range: 53–75 mm |
| Focus Mechanism | Coaxial Coarse/Fine Focus with Locking & Upper/Lower Limit Stops |
| Fine Focus Graduation | 2 µm |
| Nosepiece | Four-Position Internal Ball-Bearing Centered Revolving Turret |
| Stage | Dual-Layer Mechanical Stage, Travel Range: 30 mm × 75 mm |
| Culture Dish Holder Plate I | 99 mm × 105 mm, Inner Groove Ø68 mm (Compatible with Ø68.5 mm Round Petri Dishes) |
| Culture Dish Holder Plate II | 99 mm × 105 mm, Compatible with Rectangular Dishes (34 mm W × 77.5 mm L) |
| Culture Dish Holder Plate III | Outer Diameter 67.5 mm, Inner Aperture 20 mm |
| Condenser | Plug-in Phase Contrast Condenser, Working Distance 30 mm, Integrated Phase Annuli |
| Illumination | 6 V / 20 W Halogen Lamp with Continuously Adjustable Brightness |
| Filters | Blue Filter, Green Filter, Ground Glass Diffuser |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-made) |
| Model | BI-11 Biological Inverted Microscope |
| Instrument Type | Inverted Microscope |
| Magnification Range (Standard) | 40×–400× |
| Max Optional Magnification | 64×–1600× |
| Eyepiece | Wide-Field WF10× (Φ18 mm) |
| Objective Lenses (BI-11A) | 4×/0.10, 10×/0.25, 40×/0.65 (spring-loaded) |
| Objective Lenses (BI-11B) | 4×/0.10, 10×/0.25, 40×/0.65 (spring-loaded), 100×/1.25 (oil immersion, spring-loaded) |
| Eyepiece Tube | Monocular, 360° rotatable, inclined at 45° |
| Focus Mechanism | Coaxial coarse/fine focus, fine focus graduation: 4 µm |
| Nosepiece | BI-11A – 3-position forward-facing ball-bearing turret |
| Stage | BI-11A – fixed stage (120 mm × 120 mm) with 5-hole aperture diaphragm disc |
| Condenser | Abbe condenser (N.A. 1.25), vertically adjustable (BI-11B only) |
| Illumination | High-intensity white LED (integrated or external power supply options), compatible with halogen, tungsten-halogen, fluorescent, and incandescent sources via optional condensers |
| Optional Accessories | WF16× eyepiece, pointer eyepiece, variable-aperture condenser, movable-stage adapter, color filters (green/yellow/blue), ground glass diffuser, USB/VIDEO phototube, rechargeable LED module, 12 V/20 W halogen lamp, 5 W fluorescent lamp, 20 W incandescent lamp |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-Made) |
| Model | BI-23 |
| Instrument Type | Inverted Microscope |
| Eyepiece Configuration | Binocular |
| Optical System | Infinity-Corrected |
| Magnification Range | 40×–1000× |
| Objective Conjugate Distance | ∞ |
| Eyepiece Port Diameter | 30 mm |
| Parfocal Distance | 10 mm |
| Eyepieces | Widefield WF10X (Φ22 mm) |
| Interpupillary Adjustment Range | 48–75 mm |
| Objectives | Infinity Plan Achromat 4X/0.10 (WD 19.8 mm), 10X/0.25 (WD 5 mm), 40X/0.65 (spring-loaded, WD 0.66 mm), 100X/1.25 (spring-loaded, oil immersion, WD 0.36 mm) |
| Coverslip Thickness Specification | 0.17 mm (for 40X & 100X) |
| Eyepiece Tube | 30° inclined binocular tube with adjustable brightness |
| Focus Mechanism | Coaxial coarse/fine focus |
| fine focus graduation | 2 µm |
| Nosepiece | Four-position inward-rolling ball bearing turret with positive positioning |
| Stage | Dual-layer mechanical stage (193 mm × 155 mm) |
| travel range | 75 mm × 50 mm |
| Condenser | Abbe condenser, N.A. 1.25, vertically adjustable |
| Filters | Blue filter, ground glass |
| Built-in Field Diaphragm | Yes |
| Illumination | 3 V LED, continuously adjustable brightness |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-made) |
| Model | BI-12 |
| Instrument Type | Inverted Microscope |
| Illumination | 20 W Tungsten-Halogen Lamp (110 V / 220 V) or High-Brightness White LED (Optional) |
| Eyepiece | Wide-Field WF10× (Φ18 mm) |
| Objective Lenses | Achromatic 4×/0.10, 10×/0.25, 40×/0.65 (spring-loaded), 100×/1.25 (spring-loaded, oil immersion) |
| Magnification Range | 40×–1000× (standard) |
| Fine Focus Graduation | 4 µm |
| Stage | Fixed mechanical stage (120 mm × 120 mm), travel range 70 mm × 30 mm with vernier scale |
| Nosepiece | Four-position forward-facing ball-bearing turret with external positioning |
| Condenser | Abbe condenser (N.A. 1.25, vertically adjustable) for BI-12B |
| Optional Accessories | WF16× eyepiece, pointer eyepiece, three-position turret, blue/green/yellow filters, 5 W fluorescent lamp, USB/VIDEO trinocular photo-tube, dual-input LED power adapters (9 V / 500 mA) |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-Made) |
| Model | BI-17 Biological Inverted Microscope |
| Instrument Classification | Inverted Microscope |
| Eyepiece Configuration | Binocular |
| Magnification Range | 40×–1000× |
| Eyepieces | Wide-Field WF10× (Φ18 mm) |
| Objectives | Achromatic 4×/0.10, 10×/0.25, 40×/0.65 (spring-loaded), 100×/1.25 (spring-loaded, oil-immersion) |
| Nosepiece | Four-position inward-rolling ball bearing turret |
| Stage | Dual-layer mechanical stage (135 mm × 125 mm), travel range 75 mm × 35 mm |
| Condenser | Abbe condenser, N.A. 1.25, vertically adjustable |
| Filters | Blue filter, ground glass |
| Illuminator | 6 V / 20 W halogen lamp with brightness control |
| Focusing Mechanism | Coaxial coarse/fine focus |
| fine focus graduation | 2 µm |
| Optional Accessories | Phase contrast kits (PH-I/PH-II turret, PHP objectives), LED illuminator (9 V / 500 mA), polarizing components, infinity-corrected optical path upgrade, USB/VIDEO trinocular port, plan achromat objectives, darkfield condensers, wide-field and reticle eyepieces |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Product Category | Domestic |
| Model | 37XD Inverted Biological Microscope |
| Configuration | Trinocular |
| Observation Head | 30° inclined trinocular head, interpupillary distance adjustment range 48–75 mm |
| Eyepieces | Wide-field, high-eyepoint EW10×/22 mm |
| Objective Lenses | Infinity-corrected achromatic long-working-distance objectives — 4× (NA 0.10, WD 17.5 mm), 10× (NA 0.25, WD 8 mm), 20× (NA 0.40, WD 5.5 mm), 40× (NA 0.60, WD 3 mm) |
| Phase Contrast Objectives | PH10× (NA 0.25, WD 8 mm), PH20× (NA 0.40, WD 5.5 mm) |
| Nosepiece | Quadruple revolving nosepiece |
| Condenser | Long-working-distance condenser (NA 0.30, WD 72 mm) |
| Stage | Flat mechanical stage (160 × 250 mm) |
| Focus Mechanism | Coaxial coarse/fine focusing via nosepiece vertical movement |
| Illumination | 6 V / 30 W halogen lamp |
| Filters | 45 mm blue filter and ground glass diffuser |
| Phase Annuli | 10×–20× phase contrast annulus |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-Made) |
| Model | XSD-100 Trinocular Inverted Biological Microscope |
| Microscope Type | Inverted Microscope |
| Eyepiece Configuration | Trinocular |
| Eyepieces | Wide-field WF10X (20 mm field number) |
| Objectives | Long-working-distance achromat plan objectives PL L 10X/0.25, PL L 25X/0.40, PL L 40X/0.60 |
| Condenser | Adjustable height, NA = 0.4, working distance = 55 mm (30 mm with phase condenser) |
| Eyepiece Tube | 30° inclined trinocular tube with 100% light path split for photomicrography |
| Focusing Mechanism | Coaxial coarse/fine focus |
| fine focus graduation | 2 µm |
| Nosepiece | 4-position revolving nosepiece with ball-bearing centering |
| Stage | Dual-layer mechanical stage (200 mm × 152 mm), travel range 75 mm × 30 mm |
| Specimen Holder | Compatible with culture dishes up to Ø72 mm or 77 mm × 33 mm |
| Filter Set | Blue and green interference filters included |
| Phase Contrast Accessories | Alignment telescope (10X), plug-in phase annuli, slide-in phase annuli set (10X/25X/40X) |
| Illumination | 6 V / 20 W halogen lamp with continuous intensity control |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | OEM Manufacturer |
| Regional Category | Domestic (China) |
| Model | BI-10 Biological Microscope |
| Instrument Type | Inverted Microscope |
| Magnification Range | 40×–400× (standard) |
| Eyepieces | Wide-field WF10× (Φ18 mm), optional WF16× (Φ11 mm) and pointer eyepiece |
| Objectives | Achromatic 4×/0.10, 10×/0.25, 40×/0.65 (spring-loaded), optional 100×/1.25 (oil immersion, spring-loaded) |
| Nosepiece | Three-position (externally mounted ball-bearing detent) or optional four-position |
| Focusing Mechanism | Dual coarse/fine focusing — either separated or coaxial |
| fine-focus graduation | 4 µm per division |
| Stage | Fixed stage (120 mm × 120 mm), integrated single-lens condenser with adjustable iris diaphragm |
| Illumination | 20 W tungsten-halogen lamp (110 V / 220 V), optional 5 W fluorescent or high-intensity white LED illumination |
| Filters | Blue filter, ground glass diffuser |
| Condenser | Abbe-type, optimized for tungsten illumination |
| Eyepiece Tube | Monocular, 360° rotatable, inclined at 45° |
| Imaging Output | Optional USB/VIDEO photo-eyepiece adapter |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Product Category | Domestic |
| Model | BI-20 |
| Microscope Type | Inverted Microscope |
| Eyepiece Configuration | Binocular (30° inclination) |
| Magnification Range | 40×–1000× |
| Eyepieces | Wide-field WF10× (f = 25 mm, FOV Φ18 mm) |
| Objective Lenses | Achromatic BI-20A or Semi-Plan Achromatic BI-20B (4×/0.10, 10×/0.25, 40×/0.65 spring-loaded, 100×/1.25 spring-loaded oil-immersion) |
| Working Distance | 4× (21 mm), 10× (5 mm), 40× (0.66 mm), 100× (0.36 mm) |
| Focusing Mechanism | Coaxial coarse/fine focus with adjustable coarse tension, locking mechanism, and limit stop |
| fine focus graduation | 2 µm |
| Nosepiece | 4-position inward-rolling ball bearing turret |
| Stage | Dual-layer mechanical stage (160 × 140 mm), travel range 75 × 50 mm |
| Condenser | Abbe condenser (N.A. 1.25), vertically adjustable, with filter holder |
| Filters | Blue filter, ground glass |
| Illuminator | 6 V / 20 W halogen lamp (22 V compatible), intensity continuously adjustable |
| Optional Accessories | Phase contrast kits (PH-I/PH-II turret, PHP objectives), LED illumination modules (9 V / 500 mA adapters), polarizing components, USB/VIDEO trinocular port, infinity-corrected optical path upgrade, darkfield condensers (dry/wet), extended objective sets (5×, 20×, 60×), reticle eyepieces, teaching head (dual-view 30°), 5-position turret |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (PRC-Made) |
| Model | BI-18 Biological Microscope |
| Instrument Type | Inverted Microscope |
| Eyepiece Configuration | Binocular |
| Magnification Range | 40×–1000× |
| Eyepieces | Wide-Field WF10× (f = 25 mm, FOV Φ18 mm) |
| Interpupillary Distance | 53–75 mm |
| Objective Lenses | Achromatic: 4×/0.10 (WD 37.4 mm), 10×/0.25 (WD 6.6 mm), 40×/0.65 (spring-loaded, WD 0.64 mm), 100×/1.25 (spring-loaded, oil immersion, WD 0.19 mm) |
| Head | 30° inclined binocular tube |
| Focusing Mechanism | Coaxial coarse/fine focus with adjustable coarse tension, locking mechanism, and limit stop |
| fine focus graduation | 2 µm |
| Nosepiece | Four-position inward-rolling ball bearing turret |
| Stage | Dual-layer mechanical stage (135 mm × 125 mm) |
| travel range | 75 mm × 35 mm |
| Condenser | Abbe condenser, N.A. 1.25, vertically adjustable |
| Filters | Blue filter, ground glass |
| Illuminator | 6 V / 20 W halogen lamp (220 V or 110 V AC), intensity continuously variable |
| Optional Accessories | Phase contrast kits (PH-I/PH-II turrets, PHP objectives), LED illumination modules (9 V / 500 mA adapters), polarizing components, infinity-corrected optical components, USB/VIDEO trinocular photo-tubes, darkfield condensers (dry/wet), extended objective sets (SP and infinity-corrected), reticle eyepieces, teaching twin-head tubes |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic (China-Made) |
| Model | BID-400 Inverted Polarized Modulation Contrast Microscope |
| Instrument Type | Inverted Microscope |
| Eyepiece Configuration | Binocular |
| Optical Magnification Range | 100×–400× |
| Mechanical Tube Length | Infinity (∞) |
| Object Distance (Infinity-Corrected) | ∞ |
| Eyepieces | Widefield WF10X (Φ22 mm), Centering Eyepiece |
| Interpupillary Distance | 53–75 mm |
| Eyepiece Port Diameter | Φ30 mm |
| Parfocal Distance | 10 mm |
| Objective Types | Infinity-Corrected Long Working Distance Plan Achromatic (PLL), Phase Contrast (PHP), and Modulation Contrast (MC) Objectives (Cover Slip Thickness: 1.2 mm) |
| Objective Specifications | 10X/0.25 (WD 19.4 mm / 4.3 mm), 20X/0.40 (WD 8.0 mm), 40X/0.60 (WD 3.5 mm) |
| Nosepiece | Quintuple Revolving Nosepiece |
| Condenser | Long Working Distance Condenser (WD 55 mm), Rotating or Sliding Modulation Contrast Annulus System |
| Stage | Dual-Layer Mechanical Stage (227 × 208 mm), Travel Range 77 × 134.5 mm, Removable Scale Rule |
| Focusing Mechanism | Coaxial Coarse/Fine Focus, Fine Adjustment Graduation: 2 µm per division |
| Petri Dish Adapters | Three Interchangeable Plates (86×129.5 mm, 34×77.5 mm, 57×82 mm) |
| Illumination | 6 V / 30 W Halogen Lamp with Continuously Adjustable Brightness |
| Optional Upgrades | High-Power LED Illumination, Hexapod Nosepiece, Variable Aperture Iris Diaphragm, Additional Phase & MC Objectives |
| Brand | YANRUN |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Product Category | Inverted Microscope |
| Eyepiece Configuration | Binocular |
| Magnification Range | 40×–1000× |
| Eyepieces | Widefield WF10× (Φ20 mm) |
| Objective Lenses (BI-24A) | 4×/0.10, 10×/0.25, 40×/0.65 (spring-loaded), 100×/1.25 (spring-loaded, oil immersion) |
| Objective Lenses (BI-24B) | 4×/0.10, 10×/0.25, 20×/0.40, 40×/0.65 (spring-loaded), 100×/1.25 (spring-loaded, oil immersion) |
| Interpupillary Adjustment | Hinged binocular head with diopter correction |
| Focusing Mechanism | Coaxial coarse/fine focus with locking knob and upper/lower limit stops |
| fine focus graduation | 2 µm |
| Nosepiece | BI-24A — 4-position inward-rolling ball bearing turret |
| Stage | Dual-layer mechanical stage (210 mm × 140 mm) |
| travel range | 75 mm × 50 mm |
| Condenser | Abbe condenser, N.A. 1.25, vertically adjustable |
| Illumination | 6 V / 20 W halogen lamp with brightness control |
| Filters | Blue filter, ground glass diffuser |
| Optional Accessories | Phase contrast kits (PH-I/PH-II turret, PHP objectives), darkfield condensers (dry/wet), polarizing components, LED power adapters (9 V / 500 mA, 110 V or 230 V input), USB/VIDEO camera eyepieces, infinity-corrected optical pathway upgrade modules |
Show next
