BrandOxford Instruments
OriginUnited Kingdom
ModelPlasmaPro 800 RIE
CategoryDry Process Equipment for Semiconductor Fabrication
Etching PrincipleReactive Ion Etching (RIE) with optional Plasma Enhanced (PE) mode
Substrate CompatibilityUp to 300 mm wafers and batch processing
Electrode ConfigurationLarge-area lower electrode with liquid cooling and/or resistive heating
Endpoint DetectionLaser interferometry and/or optical emission spectroscopy (OES)
Gas DeliveryConfigurable gas cabinet with 4-, 8-, or 12-channel options
Vacuum SystemProximal turbomolecular pumping
Temperature ControlPrecision substrate temperature regulation (±0.5 °C typical stability)
ComplianceDesigned for GLP/GMP-aligned process documentation
Added to wishlistRemoved from wishlist 0
Add to compare
BrandSENTECH
OriginGermany
ModelSI 500 D
Plasma SourcePlanar Triple-Spiral Antenna (PTSA)
Substrate Temperature RangeRT to +350 °C
Vacuum SystemFully Integrated, High-Stability
Process CompatibilitySiO₂, SiNₓ, SiONₓ, a-Si, SiC, TEOS-derived films
Substrate SizeUp to 200 mm wafers or carrier-mounted substrates
Optional FeaturesLoad-lock integration, Laser Endpoint Detection, Substrate Biasing, He-backside Cooling with Real-Time Backside Temperature Sensing
Control ArchitectureSENTECH Fieldbus-Based SCADA Software with Audit-Trail-Capable UI
Compliance ContextDesigned for GLP/GMP-aligned R&D and pilot-line fabrication
Added to wishlistRemoved from wishlist 0
Add to compare
BrandOxford Instruments
OriginUnited Kingdom
ModelPlasmalab System 100
Wafer HandlingUp to 200 mm (8") single-wafer or batch (6 × 50 mm), cassette-to-cassette transfer via load-lock chamber
Substrate Temperature Range–150 °C to +700 °C
Gas DeliveryOptional 6- or 12-channel gas manifold (remotely mounted)
In-situ Endpoint DetectionLaser interferometry and/or optical emission spectroscopy (OES) compatible
Integration CapabilityCluster tool ready with robotic wafer handling
Process FlexibilityReactive ion etching (RIE), inductively coupled plasma (ICP), electron cyclotron resonance (ECR), and plasma-enhanced chemical vapor deposition (PECVD) modes
Added to wishlistRemoved from wishlist 0
Add to compare
BrandNano-Master
OriginGermany
ModelSWC-3000
Maximum Substrate Size300 mm (12") round or 230 mm × 230 mm (9" × 9") square
Control SystemMicroprocessor-based automation
Optional ModulesPVA brush station, Chemical Dispense Unit (CDU), N₂ ionizer, IR drying lamp, custom photomask/wafer chucks
