| Brand | Cubic |
|---|---|
| Origin | Hubei, China |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (China) |
| Model | PM3003Q |
| Price | USD 630 (FOB) |
| Operating Principle | Laser Light Scattering |
| Safety Rating | Non-Explosive Atmosphere Rated |
| Measurement Range | 0–50 mg/m³ (max display: 1000 mg/m³) |
| Accuracy | ±200 µg/m³ for 0–1 mg/m³ |
| Detection Principle | Optical Scattering |
| Recommended Sample Flow Rate | 2 L/min |
| Data Update Interval | 1 s |
| Operating Temperature | 30–70 °C |
| Operating Humidity | 5–95% RH (non-condensing) |
| Storage Temperature | −40–85 °C |
| Storage Humidity | 0–95% RH (non-condensing) |
| Supply Voltage | DC 5 V ± 0.2 V (ripple < 100 mV) |
| Average Current Consumption | <150 mA |
| Standby Current | <25 mA |
| Interface | UART (TTL 3.3 V logic level) |
| Dimensions | 90.8 × 60.2 × 37.6 mm (W × H × D) |
| Brand | Cubic |
|---|---|
| Origin | Hubei, China |
| Model | PM2008MSE |
| Detection Principle | Optical Scattering (Laser Nephelometry) |
| Measurement Range | 0–1000 µg/m³ (PM1.0, PM2.5, PM10) |
| Resolution | 0.3 µm |
| Accuracy (PM2.5) | ±10 µg/m³ (≤100 µg/m³), ±10% of reading (>100 µg/m³) |
| Accuracy (PM10) | ±20 µg/m³ (≤100 µg/m³), ±20% of reading (>100 µg/m³) |
| Data Update Interval | 1 s |
| Warm-up Time | ≤8 s |
| Operating Temperature | −10 to +50 °C |
| Relative Humidity | 0–95% RH (non-condensing) |
| Storage Conditions | −20 to +60 °C, 0–95% RH |
| Supply Voltage | DC 5 V ±0.1 V (ripple <50 mV) |
| Operating Current | ≤100 mA |
| Standby Current | ≤200 µA |
| Interface | UART (3.3 V logic), I²C (3.3 V logic) |
| Dimensions | 48 × 40 × 12 mm (W × H × D) |
| Shielding | Full-metal EMI enclosure |
| Design | Ultra-thin profile (12 mm height) |
| Brand | Cubic |
|---|---|
| Origin | Hubei, China |
| Manufacturer Type | Authorized Distributor |
| Country of Origin | China |
| Model | PM5000S |
| Operating Principle | Light Scattering (Laser Nephelometry) |
| Safety Rating | Non-Explosive Atmosphere Rated |
| Measurement Channels | 0.3, 0.5, 1.0, 2.5, 5.0, and 10.0 µm |
| Calibration Compliance | JJF 1190–2008 “Calibration Specification for Airborne Particle Counters” |
| Output Format | Particle concentration in pcs/L per channel |
| Sampling Flow Rate | 2.83 L/min (standard) |
| Detection Efficiency | ≥50% at 0.3 µm |
| Brand | CUBIC INSTRUMENTS |
|---|---|
| Origin | Hubei, China |
| Manufacturer Type | Authorized Distributor |
| Country of Origin | China |
| Model | Gasboard-9056 |
| Measurement Principle | Forward Light Scattering (Laser) |
| Safety Rating | Explosion-Proof (Ex d IIB T4 Gb) |
| Measurement Range | 0–5 mg/m³ |
| Resolution | < 0.1 mg/m³ |
| Accuracy | ±10% of reading |
| Relative Error | ≤ ±20% |
| Sampling Method | Heated Extractive Probe with Hot-Wet Return |
| Isokinetic Sampling Capability | Yes |
| Maximum Sampling Flow Rate | 200 L/min |
| Operating Environment | -20°C to +60°C, RH ≤ 95% non-condensing, IP65 enclosure |
| Brand | CUBIC INSTRUMENTS |
|---|---|
| Origin | Hubei, China |
| Measurement Principle | Optical Light Scattering |
| Safety Classification | Non-Explosion-Proof |
| Range | 0–20 mg/m³ |
| Accuracy | ≤ ±10% F.S. |
| LOD | 0.01 mg/m³ |
| Zero Drift | ±2% F.S./24h |
| Span Drift | ±2% F.S./24h |
| Operating Temp. | −20 to 50°C |
| Humidity | 5–95% RH (non-condensing) |
| Flue Gas Temp. Tolerance | <300°C |
| Data Update Rate | 1 Hz |
| Power Supply | DC 12 V ±0.5 V (ripple <100 mV) |
| Avg. Current Draw | <500 mA |
| Interface | UART_TTL (3.3 V logic) |
| Dimensions (W×H×D) | 272 × 111 × 193 mm |
| Anti-Clogging | Pneumatic Air Curtain Protection |
| Enclosure Rating | IP65-equivalent (based on module integration context) |
| Brand | Cubic |
|---|---|
| Origin | Hubei, China |
| Model | PM3003S |
| Measurement Principle | Laser Light Scattering (90° Detection Geometry) |
| Safety Rating | Explosion-Proof (Ex ib IIB T4 Gb) |
| Measurement Range | 0–1000 µg/m³ |
| Accuracy | PM1.0: ±10 µg/m³ or ±10% of reading |
| PM2.5 | ±10 µg/m³ or ±10% of reading |
| PM10 | ±15 µg/m³ or ±15% of reading |
| TSP | ±20 µg/m³ or ±20% of reading |
| Sampling Flow Rate | 1.0 L/min (pump-assisted) |
| Data Refresh Interval | 1 s |
| Operating Temperature | −30 °C to +70 °C |
| Relative Humidity | 0–95% RH (non-condensing) |
| Power Supply | DC 5.0 V ±0.1 V (ripple <50 mV) |
| Current Consumption | <150 mA (operational), <25 mA (standby) |
| Output Interfaces | Analog voltage (0–5 V or 0–10 V configurable), UART TTL (3.3 V logic level) |
| Dimensions | 82 × 40.2 × 26.3 mm (W × H × D) |
| Brand | Cubic |
|---|---|
| Origin | Hubei, China |
| Manufacturer Type | Authorized Distributor |
| Regional Classification | Domestic (China) |
| Model | PM2107 |
| Pricing | Available Upon Request |
| Operating Principle | Laser Light Scattering |
| Measurement Range | 0–1000 µg/m³ |
| Accuracy | ±15 µg/m³ or ±15% of reading |
| Detection Principle | Laser Scattering |
| PM2.5 Range | 0–1000 µg/m³ |
| Power-On Stabilization Time | ≤8 s |
| Data Update Interval | 1 s |
| Environmental Conditions (Calibration) | 25°C ±2°C, 50% RH ±10%, referenced to TSI AM510/8530 |
| Operating Temperature | −10°C to +50°C |
| Operating Humidity | 5–95% RH (non-condensing) |
| Storage Temperature | −30°C to +60°C |
| Storage Humidity | 0–95% RH (non-condensing) |
| Supply Voltage | DC 5.0 V ±0.1 V, ripple <50 mV |
| Operating Current | ≤100 mA |
| Standby Current | <20 mA |
| Output Interfaces | UART TTL (3.3 V logic), PWM (default 5 V, 3.3 V configurable) |
| Dimensions | 58.7 mm (W) × 45 mm (H) × 13.9 mm (D) |
| Brand | Cubic |
|---|---|
| Origin | Hubei, China |
| Model | PM3006S |
| Measurement Principle | Laser Light Scattering |
| Safety Rating | Non-Explosive |
| Measurement Range | 0–1000 µg/m³ (detection limit: 30 mg/m³) |
| Resolution | 1 µg/m³ |
| Accuracy | ±10 µg/m³ or ±10% (PM1.0/PM2.5), ±15 µg/m³ or ±15% (PM10), ±20 µg/m³ or ±20% (TSP) |
| Operating Temperature | −40 °C to +70 °C |
| Relative Humidity | 0–95% RH (non-condensing) |
| Power Supply | DC 5.0 V ±0.1 V, ripple <50 mV |
| Current Consumption | ≤250 mA (operational), <20 mA (standby) |
| Output Interfaces | UART TTL (3.3 V / 5 V), I²C (3.3 V / 5 V) |
| Dimensions | 85 × 74 × 24.9 mm (W × H × D) |
| Warm-up Time | ≤8 s |
| Data Refresh Rate | 1 s |
| Brand | Cubic |
|---|---|
| Origin | Hubei, China |
| Model | OPM-6303M |
| Measurement Principle | Optical Light Scattering |
| Safety Rating | Non-Explosion-Proof |
| Measurement Range | 0–30 mg/m³ |
| PM₁.₀/PM₂.₅ Accuracy | ±10 µg/m³ (≤100 µg/m³), ±10% of reading (100–1000 µg/m³) |
| PM₁₀ Accuracy | ±15 µg/m³ (≤100 µg/m³), ±15% of reading (100–1000 µg/m³) |
| TSP Accuracy | ±20 µg/m³ (≤100 µg/m³), ±20% of reading (100–1000 µg/m³) |
| Warm-up Time | ≤8 s |
| Data Update Interval | 1 s |
| Operating Temperature | −30 to +70 °C |
| Relative Humidity | 0–95% RH (non-condensing) |
| Storage Temperature | −40 to +85 °C |
| Power Supply | DC 12 V |
| Average Current Draw | ≤4.5 A |
| Communication Interface | RS485 |
| Sampling Flow Rate | 1 L/min (standard, customizable) |
