| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Manufacturer |
| Instrument Type | Flame and Graphite Furnace AAS |
| Monochromator | Czerny-Turner grating monochromator with 1800 lines/mm grating |
| Optical System | Single-beam |
| Background Correction | Deuterium lamp + Self-reversal (Self-absorption) background correction |
| Wavelength Range | 190–900 nm |
| Spectral Bandwidth | 0.1/0.2/0.4/1.0/2.0 nm (5-step automatic switching) |
| Cu Detection Limit (Flame) | ≤0.003 µg/mL |
| Cd Characteristic Mass (GFAAS) | 0.3×10⁻¹² g |
| Cd Detection Limit (GFAAS) | 0.2×10⁻¹² g |
| Graphite Furnace Temp. Range | Room temperature to 3000 °C |
| Max. Sample Volume (GFAAS) | 70 µL |
| Background Correction Capacity | >60× at up to 1.0 A absorbance |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Instrument Type | Flame and Graphite Furnace AAS |
| Optical System | Single-beam Czerny-Turner monochromator with 1800 lines/mm holographic grating |
| Wavelength Range | 190–900 nm |
| Spectral Bandwidth | 0.1 / 0.2 / 0.4 / 1.0 / 2.0 nm (5-step auto-switching) |
| Wavelength Accuracy | ±0.1 nm |
| Wavelength Repeatability | ≤0.05 nm |
| Baseline Stability | ≤0.003 A/30 min (dynamic), ≤0.002 A/30 min (static) |
| Resolution | <0.1 nm |
| Flame Cu Detection Limit | ≤0.003 µg/mL |
| Flame Cu Characteristic Concentration | ≤0.02 µg/mL/1% |
| Graphite Furnace Cd Characteristic Mass | 0.3×10⁻¹² g |
| Graphite Furnace Detection Limit | 0.2×10⁻¹² g |
| Graphite Furnace Temperature Range | Room temperature to 3000 °C |
| Max. Graphite Furnace Ramp Rate | ≥3000 °C/s (optical control), ≥2000 °C/s (power control) |
| Background Correction | D₂-lamp and self-absorption (AAS) modes, correction capacity >60× at 1.0 A background absorbance |
| Sample Introduction | Manual or automated (flame/graphite furnace/hydride generation) |
| Dimensions (W×D×H) | 880 × 540 × 450 mm |
| Weight | 125 kg |
| Power Supply | AC 220 V, 50 Hz |
| Main unit | 500 W |
| Graphite furnace module | 5 kW |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Instrument Type | Flame-Graphite Furnace Hybrid AAS |
| Background Correction | Dual-mode Deuterium Lamp + Longitudinal AC Zeeman |
| Optical Grating | 1800 lines/mm |
| Wavelength Range | 190–900 nm |
| Spectral Bandwidth | 0.1/0.2/0.4/1.0/2.0 nm (auto-switchable) |
| Flame Cu Detection Limit | ≤0.003 µg/mL |
| Graphite Furnace Cd Characteristic Mass | 0.5×10⁻¹² g |
| Graphite Furnace Detection Limit | 10×10⁻¹² g |
| Max Graphite Furnace Temp | 2700 °C |
| Heating Rate | ≥2500 °C/s |
| Background Correction Capacity | >60× (flame, D₂), >100× (GF, Zeeman at ~2.0 Abs) |
| Auto-sampler Compatibility | AS-600 Integrated Flame/GF Autosampler |
| Software Compliance | Audit Trail, Electronic Signature, Role-Based Access Control, 21 CFR Part 11 Readiness |
