| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Instrument Type | Portable |
| Instrument Category | Fourier Transform |
| Spectral Resolution | <1 cm⁻¹ |
| Wavenumber Accuracy | <0.01 cm⁻¹ |
| Spectral Range | 5000–500 cm⁻¹ |
| Interferometer | Domestic High-Stability Cubic Corner Retroreflector Interferometer (Lifetime >10 years) |
| Beam Splitter | ZnSe for Mid-IR, Humidity-Resistant |
| Detector | Desiccated High-Sensitivity DLaTGS with Integrated ADC |
| Light Source | Long-Life Mid-IR Ceramic Source |
| Laser | Solid-State Laser (Lifetime >10 years) |
| ATR Crystal | Monolithic Diamond Embedded in Passivated Stainless Steel |
| Display | 7-inch Capacitive Touchscreen Running Windows 10 |
| Battery | Rechargeable Li-ion, 4 h Continuous Operation |
| Power Input | 100–240 VAC, 50–60 Hz |
| Dimensions | 260 × 163 × 128 mm (with auto-pressure ATR head) |
| Weight | <4.5 kg |
| Operating Temperature | −10 °C to +40 °C |
| Storage Temperature | −20 °C to +55 °C |
| Environmental Sealing | Integrated Desiccant Dry Tube + Real-Time Internal Humidity/Temperature Monitoring & Alert |
| Connectivity | Wi-Fi 802.11ac, Bluetooth 5.0, USB-C Data/Charging Port |
| Onboard Camera | Integrated for Sample Imaging |
| Software | Fully Localized Chinese FTIR Analysis Suite with Automated “Acquire–Analyze–Report” Workflow |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Instrument Type | Laboratory FT-IR Spectrometer |
| Spectral Range | 5000–500 cm⁻¹ (ZnSe anti-humidity version) |
| Spectral Resolution | < 0.9 cm⁻¹ |
| Wavenumber Accuracy | < 0.01 cm⁻¹ |
| Interferometer | Domestic high-stability立体角镜 interferometer with permanent alignment |
| Beam Splitter | Ge-coated KBr, optimized for mid-IR |
| Detector | Fast-response pyroelectric detector |
| IR Source | High-energy SiN mid-IR source |
| Laser | Solid-state diode laser (>10 yr lifetime) |
| Environmental Sealing | Integrated desiccant system with real-time internal T/RH monitoring and auto-humidity alarm |
| Dimensions | 17 × 39.5 × 22.3 cm |
| Connectivity | Ethernet interface |
| Power | 100–240 VAC, 50–60 Hz |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Instrument Class | Laboratory-grade Infrared Spectral Analyzer |
| Model | Omni-λ300i |
| Wavenumber Range | 4000–25000 cm⁻¹ |
| Spectral Resolution | 0.08 nm (with 1200 g/mm grating) |
| Signal-to-Noise Ratio | 8000:1 |
| Stray Light Level | ≤1×10⁻⁵ |
| Focal Length | 320 mm |
| f-number | f/4.2 |
| Optical Design | Czerny-Turner with Aspheric Image Correction |
| Grating Size | 68×68 mm |
| Grating Tower | Triple-grating turret |
| Interface | USB 2.0 (standard), RS-232 (optional) |
| Slit Width Adjustment | 0.01–3 mm (manual or motorized option) |
| Slit Height Options | 2 mm / 4 mm / 14 mm |
| Focal Plane Dimensions | 30 mm (W) × 14 mm (H) |
| Optical Axis Height | 146 mm |
| Wavelength Accuracy | ±0.15 nm |
| Wavelength Repeatability | ±0.08 nm |
| Minimum Scan Step | 0.005 nm |
| Dispersion | 2.3 nm/mm (at 435.8 nm) |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Instrument Type | Laboratory FTIR Spectrometer |
| Spectral Range | 5000–500 cm⁻¹ (FOLI 20-Z) / 7500–400 cm⁻¹ (FOLI 20-ZE) |
| Resolution | ≤2 cm⁻¹ |
| Wavenumber Accuracy | ≤0.01 cm⁻¹ |
| Signal-to-Noise Ratio (S/N) | ≥40,000:1 (at 4 cm⁻¹, 1 min scan) |
| Transmittance Accuracy | ≤0.1% τ |
| Beam Splitter | ZnSe (standard) or KBr (FOLI 20-ZE models) |
| Detector | Standard DLaTGS |
| Laser | Solid-state He–Ne reference laser |
| Dimensions | 550 × 450 × 230 mm |
| Weight | 20 kg |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Instrument Type | Laboratory Benchtop FTIR Spectrometer |
| Spectral Resolution | < 0.4 cm⁻¹ |
| Wavenumber Accuracy | < 0.005 cm⁻¹ |
| Spectral Range | 8000–350 cm⁻¹ (standard), optional 5000–500 cm⁻¹ |
| Interferometer | Cube-corner Retroreflector Michelson Interferometer |
| Beam Splitter | Hygroscopic-resistant ZnSe |
| Detector Options | High-sensitivity DLaTGS, TE-cooled MCT, or Liquid-nitrogen-cooled MCT |
| Laser Source | Solid-state HeNe laser (10+ year lifetime) |
| Optical Mirrors | Gold-coated (reflectivity >98% above 2 µm, +5% vs aluminum) |
| Dimensions (L×W×H) | 685 × 415 × 223 mm |
| Weight | 25 kg |
| Sample Compartment | Large-volume, modular, fully accessible for in situ accessories |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Instrument Type | Portable |
| Instrument Principle | Fourier Transform Infrared (FT-IR) |
| Spectral Resolution | 1 cm⁻¹ |
| Spectral Range | 500–5000 cm⁻¹ |
| Interferometer | Cube Corner Michelson Interferometer |
| IR Source | Air-Cooled Ceramic Source |
| Beam Splitter | Zinc Selenide (ZnSe) |
| Detector | High-Sensitivity DLATGS |
| ATR Sampling | Single-Bounce Diamond ATR |
| Operating Temperature | −5 to 40 °C |
| Operating Humidity | 0–100% RH |
| Weight | 10 kg |
| Dimensions | 41 × 32 × 17 cm |
| Battery Life | Up to 4 hours (internal Li-ion) |
| Power Input | 18–24 V DC (vehicle battery compatible) or 100–240 V AC, 50–60 Hz, 20 W |
| Control Interface | 10-inch capacitive touchscreen (Windows 10 OS optional) |
| Reference Libraries | Hazardous Chemicals, Explosives, Narcotics, Pesticides, Pharmaceuticals, White Powders, Gases |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Instrument Type | Laboratory FTIR Spectrometer |
| Spectral Range | 8000–350 cm⁻¹ / 5000–500 cm⁻¹ |
| Spectral Resolution | ≤0.4 cm⁻¹ |
| Wavenumber Accuracy | ≤0.005 cm⁻¹ |
| Interferometer | Domestic High-Stability Cubic Corner Retroreflector Interferometer |
| Beamsplitter | ZnSe (Moisture-Resistant), Optional KBr |
| Detectors | Liquid-N₂-Cooled MCT (≥10 h hold time), DLaTGS (Room-Temperature, Humidity-Resistant) |
| Scan Speed Options | 2.5K–60K points/sec (6 selectable steps) |
| Software | Windows 10–Based Native Chinese GUI with ASTM E1421–compliant spectral processing, automated channel switching, K-M transformation, background validity tracking, and GLP-ready audit trail logging |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Instrument Type | Fourier Transform |
| Spectral Range | 7800–350 cm⁻¹ (KBr), 5000–500 cm⁻¹ (ZnSe) |
| Resolution | 0.9 cm⁻¹ |
| Signal-to-Noise Ratio | ≥50,000:1 |
| Wavenumber Accuracy | ≤0.005 cm⁻¹ |
| Interferometer | Integrated Cube-Corner Mirror Design, Permanent Alignment, >10-Year Lifetime |
| Detector | Moisture-Resistant High-Sensitivity DLaTGS with Built-in ADC |
| Source | Long-Life Mid-IR Ceramic Source (1550 K) |
| ATR Crystal | Single-Crystal Diamond |
| Dimensions (H×W×D) | 210 × 310 × 215 mm |
| Weight | 8 kg |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Instrument Type | Fourier Transform |
| Spectral Resolution | ≤0.25 cm⁻¹ |
| Signal-to-Noise Ratio (SNR) | ≥55,000:1 |
| Wavenumber Accuracy | ±0.005 cm⁻¹ |
| Spectral Range (Standard) | 8000–350 cm⁻¹ |
| Extended Range (Optional) | 12800–4000 cm⁻¹ |
| Interferometer | Cube Corner Retroreflector-Based Michelson Design |
| Detector Interface | Dual-Channel 32-bit ADC Architecture |
| Standard Detector | Room-Temperature DLaTGS |
| Optional Detectors | Liquid-Nitrogen-Cooled MCT, TE-Cooled MCT, LN₂-Cooled InSb, TE-Cooled InGaAs, LN₂-Cooled Ge |
| Beam Splitter Options | Ge-Coated KBr, Quartz, CaF₂, ZnSe |
| Source Options | Ceramic Globar, Tungsten-Halogen |
| Sample Compartment | Transmission-Compatible with Vacuum/N₂-Purged External Ports |
| Optional Accessories | TGA-FTIR Coupling Module, GC-FTIR Interface, UHV-Ready External Chamber, Gas Cells (2 cm–20 m), Integrating Sphere, In Situ Transmission/DRIFTS Cells, Micro-FTIR, ATR Probes (Including Mid-IR Fiber ATR), Specular Reflection Stage |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Instrument Category | Domestic |
| Model | FI-RXF100-RT |
| Price Range | USD 35,000 – 42,000 |
| Instrument Type | Fourier Transform Infrared (FTIR) |
| Configuration | Benchtop Laboratory System |
| Detector Options | DLaTGS or MCT |
| Optical Window Pathlengths | 30 µm, 50 µm, 100 µm, 200 µm, and custom pathlengths |
| Transmission Module Design | Motorized 5-position rotating turret (4 sample positions + 1 cleaning position) |
| Crystal Material | High-transmission ZnSe |
| Rotation Control | Bidirectional (CW/CCW) with mechanical indexing pins for positional repeatability < ±0.1° |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Instrument Type | Laboratory Benchtop FTIR Emission Spectrometer |
| Spectral Range | Standard 500–5000 cm⁻¹ (Optional: 400–7500 cm⁻¹, 400–10000 cm⁻¹, or extended to 12500 cm⁻¹ in NIR) |
| Spectral Resolution | <2 cm⁻¹ (Typical operational resolution: 8 cm⁻¹) |
| Detector Configuration | Dual-detector mounting positions (RT DTGS, liquid-N₂-cooled MCT, or InGaAs) |
| Optical Path | Selectable focused or collimated beam path |
| Beam Splitter | ZnSe substrate (standard) |
| Interferometer | Permanently aligned Michelson interferometer with solid-state laser reference |
| Power Supply | 100–240 VAC, 50–60 Hz, 20 W |
| Dimensions | 44 × 33 × 18 cm (W×D×H, including emission baffle) |
| Weight | 12 kg |
| Operating Environment | 5–40 °C, 0–100% RH |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Instrument Type | Fourier Transform |
| Spectral Resolution | ≤0.25 cm⁻¹ |
| Wavenumber Accuracy | <0.01 cm⁻¹ |
| Vacuum Level | ≤0.2 mbar |
| Spectral Range (Standard) | 6000–50 cm⁻¹ |
| Extended Range | 12500–10 cm⁻¹ |
| Interferometer | Domestic High-Stability Retroreflector-Based Interferometer |
| Beam Splitter Options | KBr, CaF₂, Quartz, ZnSe |
| Detector Options | DLaTGS (standard), InGaAs, MCT, Liquid-He-Cooled Bolometer |
| Light Source Options | Ceramic IR Source (standard), Water-Cooled Hg Arc Lamp, Tungsten Filament Lamp |
| ATR Accessory | Diamond Crystal (Vacuum-Compatible) |
| Software | Windows 10–Based Full Chinese GUI with Spectral Library Management, Quantitative Analysis, and Automated CO₂/H₂O Subtraction |
| Brand | ZOLIX |
|---|---|
| Model | FI-RXF100-G |
| Instrument Type | Portable FTIR Gas Analyzer |
| Spectral Range | 500–5000 cm⁻¹ |
| Spectral Resolution | <1 cm⁻¹ (software-selectable: 2, 4, or 8 cm⁻¹) |
| Optical Design | Michelson Interferometer with Solid-Angle Retroreflector Mirrors |
| Beam Splitter | ZnSe, Anti-Humidity Coated |
| Detector Options | DTGS (ambient-temperature), Thermoelectrically Cooled MCT, or Liquid-Nitrogen-Cooled MCT |
| Light Source | Air-Cooled Mid-IR Ceramic Source (1550 K) |
| Laser | Solid-State Stabilized Reference Laser (≥10 yr lifetime) |
| Gas Cell | Multi-Pass Stainless Steel Cell (5–9.8 m pathlength, heated to 180 °C) |
| System Dimensions (L×W×H, excl. handles) | 590 × 430 × 176 mm |
| Weight | 18 kg (fully integrated configuration) |
| Response Time (T₉₀) | <120 s |
| Spectral Repeatability | <0.01 cm⁻¹ |
| Linearity Error | ≤±2% F.S. |
| Sampling Modes | Single-shot, Continuous, or Automated Sequence Acquisition |
