| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Product Origin | Domestic (China) |
| Model | Helios |
| Pricing | Available Upon Request |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Product Origin | Domestic (China) |
| Model | SCS10-Film |
| Pricing | Upon Request |
| Spectral Range | 300–1700 nm |
| Wavelength Accuracy | ±0.2 nm (@ 1200 g/mm grating, 500 nm) |
| Scan Interval | 0.1–10 nm (default 10 nm) |
| Bandwidth | 0.1–10 nm (default 5 nm) |
| Light Source | 150 W stabilized xenon lamp (optical stability ≤0.4%) |
| Modulation Frequency | 4–400 Hz |
| Detector | Calibrated Si photodiode |
| DC Sensitivity | 100 nA |
| AC Sensitivity | 2 nV |
| Repeatability | <0.6% (<0.3% from 400–1000 nm) |
| Scan Speed | <1 min per spectral response curve |
| Sample Stage | 156 mm × 156 mm probe station (customizable) |
| max sample area | 300 mm × 300 mm |
| Mapping Resolution | 0.5 mm |
| Mapping Speed | 20 points/s (@ 0.5 mm step) |
| Instrument Dimensions | Host unit: unspecified |
| Sample chamber | unspecified |
| Control cabinet | 800 mm × 600 mm × 1300 mm |
| Software | Windows 7-based proprietary control & analysis suite with calibration traceability |
| Origin | Beijing, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (China) |
| Model | LensMechanix |
| Price Range | USD 7,000 – 14,000 |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | OEM Manufacturer |
| Country of Origin | China |
| Model | SGM100 |
| Pricing | Upon Request |
| Focal Length | 100 mm |
| f-number | f/3 |
| Optical Layout | Crossed Czerny–Turner |
| Spectral Range | 200–1100 nm |
| Stray Light | <0.1% |
| Detector | 3648-pixel linear CCD array |
| Spectral Resolution (FWHM) | 0.05–18.8 nm (configurable via grating and slit selection) |
| Sensitivity | 20,000 counts/µW·ms |
| Signal-to-Noise Ratio | 300:1 |
| A/D Resolution | 16-bit |
| Integration Time | 7 ms – 65,535 ms |
| Interface | USB 2.0 (8 Mbps), DB-15 I/O (4-in / 4-out) |
| Power Supply | USB 5 V DC or external adapter with buck-boost regulation |
| EMI Shielding | Integrated RF/EMI-optimized enclosure |
| Mechanical Construction | Monolithic aluminum housing |
| Internal Calibration Storage | High-capacity flash memory for wavelength calibration, radiometric correction, and colorimetric coefficients |
| Onboard Processing | High-performance embedded CPU for real-time spectral preprocessing and color space conversion |
| Origin | USA |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Import Status | Imported |
| Model | OpticStudio 2017 |
| Price Range | USD $7,200 – $14,400 (based on perpetual license tiers) |
| Brand | ZOLIX |
|---|---|
| Model | ZAMP |
| Type | Transimpedance (Current-to-Voltage) Amplifier |
| Input Impedance Range | 1 mΩ to 100 GΩ (8 decades) |
| Gain Range | 10³–10¹⁰ V/A |
| Output Noise Voltage | ≤ 0.5 mV (RMS, DC–10 kHz) |
| Input Current Range | ±5 mA |
| Output Voltage Range | ±5 V |
| Gain Accuracy | ±2% (10³–10⁸), ±5% (10⁹–10¹⁰) |
| Power Supply | Dedicated AC adapter (ZAMP-A) |
| Dimensions | 195 × 121 × 88 mm |
| Compliance | CE-marked, RoHS-compliant, designed for laboratory-grade optical signal conditioning in accordance with IEC 61326-1 (EMC for measurement equipment) |
| Brand | ZOLIX |
|---|---|
| Model | DCS200PC |
| Counting Rate | 100 Mcps |
| Analog Input Channels | 4 (0–10 V, 16-bit A/D, 1 MS/s per channel) |
| Analog Output Channels | 2 (0–10 V) |
| Interface | USB 2.0 |
| Certification | CE |
| Power Supply | DC 24 V, 0.3 A |
| Dimensions | 240 × 240 × 120 mm |
| Weight | 3.3 kg |
| Brand | Ophir |
|---|---|
| Origin | France |
| Sensor Type | Photodiode-based |
| Max Continuous Power | 3 W (with built-in attenuator) |
| Power Range | 10 pW – 3 W |
| Wavelength Range | 190–1100 nm |
| Linearity | ±0.5% (up to 2 mW), ±1% (with attenuator, up to 3 W) |
| Damage Threshold | 10 W/cm² (CW), 0.1 J/cm² (pulsed, 10 ns) |
| Output Signal | Analog voltage (1 V per 1 W typical) |
| Connector | BNC |
| Brand | ZOLIX |
|---|---|
| Model | CHAMELEON-100 |
| Origin | Beijing, China |
| Manufacturer | ZOLIX (OEM/ODM Capable) |
| Category | Spectroradiometric LED Characterization System |
| Spectral Range | 380–780 nm |
| Spectral Resolution | 2.5 nm |
| Measurement Speed | ≤30 ms per spectrum |
| Photometric Accuracy | Luminous Intensity ±7%, Dominant Wavelength ±1 nm, Chromaticity Coordinates (x,y) ±0.005 (vs. stable reference lamp) |
| Photometric Repeatability | Luminous Intensity ±2%, Dominant Wavelength ±0.3 nm, (x,y) ±0.002 |
| Luminous Intensity Range | 5 mcd – 30,000 mcd |
| Luminous Flux Range | 20 mlm – 200 lm |
| Interface | USB 2.0 |
| Power | USB bus-powered (5 V DC) |
| Dimensions (Spectrometer Only) | 140 × 80 × 180 mm |
| Calibration Traceability | NIST-traceable |
| compliant with CIE S 025/E | 2015 and CIE 127:2007 |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Manufacturer |
| Origin Category | Domestic |
| Model | LBIC |
| Price Range | USD 14,000 – 28,000 |
| Excitation Source | Multiple stabilized continuous-wave lasers (e.g., 405 nm, 532 nm, 635 nm, 785 nm) |
| Laser Power Range | 0–30 mW, continuously adjustable |
| Focused Spot Size | < 50 µm |
| Power Stability | < 1% RMS over 8 hours |
| Measurement Repeatability | < 2% (RSD) |
| Microscopy | Interchangeable 10× and 20× objective lenses |
| Monitoring Camera | 1.3 MP industrial CMOS camera |
| Maximum Sample Area | 100 mm × 100 mm |
| XY Stage Resolution | 0.625 µm (closed-loop stepper motor) |
| Operating Temperature | 10–35 °C |
| Calibration Standard | NIM-traceable Si or InGaAs photodetectors |
| Compliance | ISO/IEC 17025-aligned calibration procedures, compatible with GLP documentation workflows |
| Brand | ZOLIX |
|---|---|
| Model | ZLX-ES Series |
| Origin | Beijing, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Product Origin | Domestic (China) |
| Pricing | Upon Request |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Product Type | Domestic Metrological Standard System |
| Model | UV-Vis Spectrophotometer Calibration Standard System |
| Pricing | Upon Request |
| Brand | SRS/Stanford Research Systems |
|---|---|
| Model | SR540 |
| Frequency Range | 4 Hz to 3.7 kHz (inner slot: 4–400 Hz |
| outer slot | 400–3700 Hz) |
| Phase Stability | 0.2°–0.5° |
| Frequency Accuracy | <2% |
| Output Signal | 5 V TTL (HCT-compatible), BNC |
| Control Interface | Front-panel thumbwheel + external 0–10 V analog input |
| Reference Output | Sync TTL pulse with adjustable phase offset |
| Blade Material | Chemically blackened, demagnetized brass |
| Blade Thickness | 0.5 mm |
| Diameter | 102 mm |
| Slot Configurations | Dual concentric slots (inner + outer) |
| Dimensions (Controller) | 216 × 89 × 343 mm |
| Weight (Controller) | 3.2 kg |
| Motor Life | >6000 hours |
| Compliance | CE, RoHS, FCC Class A |
| Brand | Sigma |
|---|---|
| Origin | Japan |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | SGRM-200 |
| Pricing | Available Upon Request |
| Brand | Ophir |
|---|---|
| Origin | France |
| Type | Pyroelectric Energy Sensor |
| Max. Repetition Rate | 25 kHz |
| Pulse Width Range | 10 ns – 20 ms |
| Energy Range | 10 µJ – 50 J |
| Spectral Range | 0.19–20 µm (with appropriate absorber) |
| Calibration Uncertainty | ±3% (k=2) |
| Rise Time | ~1.5 ms (BF-type) |
| Damage Threshold | 1 J/cm² (1064 nm, 10 ns) |
| Interface | USB or RS-232 (via StarLab or Nova II meter) |
| Brand | ZOLIX |
|---|---|
| Model | MAMOS Series |
| Origin | Beijing, China |
| Manufacturer | ZOLIX Optics Co., Ltd. |
| Type | Modular Magneto-Optical Kerr & Reflective Magnetic Circular Dichroism (RMCD) Measurement System |
| Core Capabilities | Micro-area MOKE imaging, RMCD spectroscopy, polarization-resolved mapping, time-resolved magnetization dynamics |
| Laser Source | 532 nm narrow-linewidth laser (Δλ < 0.00001 nm, M² < 1.2, power stability ±2% RMS over 4 h) |
| Spatial Resolution | ≤300 nm (at 532 nm) |
| Kerr Angle Resolution | ~0.5 mdeg (~8.7 µrad) |
| Polarization Control | Motorized polarizer/analyzer with 0.0144° angular resolution |
| Imaging Sensor | Sony 1-inch CMOS, 20 MP, 15 fps @ 5K, 50 fps @ 1.8K |
| Precision Stage | XYZ motorized stage (120 × 120 × 40 mm travel), XY step resolution 40 nm, Z step resolution 10 nm, load capacity >10 kg |
| Optical Architecture | All-reflective, non-magnetic objective or aspheric lens design |
| Software | Modular GUI supporting automated MOKE/RMCD/Raman/PL/SHG scanning, polarization sweeps, script-based sequencing (Python-compatible), GLP-compliant data logging with timestamped metadata and audit trail |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | OEM Manufacturer |
| Regional Category | Domestic (China) |
| Model | TIMART |
| Price Range | USD 110,000 – 138,000 |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Product Line | ZLX-AS Series |
| Optical Configuration | Dual-beam and single-beam configurable |
| Spectral Range | 200–2500 nm (model-dependent) |
| Stray Light | <5×10⁻⁹ (UV-Vis high-accuracy configuration) |
| Wavelength Accuracy | ±0.05 nm (UV-Vis), ±1 nm (NIR) |
| Photometric Accuracy | ±0.05%T (UV-Vis standard mode), ±2% (NIR & field-deployable configurations) |
| Spectral Resolution | ≤5 nm (adjustable scan step: 0.1–10 nm) |
| Beam Parallelism | ≤±5° |
| Sample Positioning | Motorized XYZ + θy/θz angular adjustment (±45°/±90°) |
| Compliance | ASTM E903, ISO 9050, GB/T 2680, EN 410, ANSI Z87.1, USP <857>, FDA 21 CFR Part 11 (software audit trail enabled) |
