Photometer Haze Meter Gloss Meter
Filter
Showing 61–90 of 112 results
| Brand | Konica Minolta |
|---|---|
| Origin | Japan |
| Model | UG60 |
| Measurement Angle | 60° |
| Aperture Size | 9 × 15 mm |
| Gloss Range | 0.0–1,000 GU |
| Resolution | 0.1 GU (0–99.9 GU), 1 GU (100–2,000 GU) |
| Repeatability | ±0.2 GU (0–99.9 GU), ±0.2% of reading (100–2,000 GU) |
| Inter-instrument Agreement | ±0.5 GU (0–99.9 GU), ±0.5% of reading (100–2,000 GU) |
| Standards Compliance | ISO 2813, ISO 7668, ASTM D 523, ASTM D 2457, DIN 67530, JIS Z 8741, BS 3900, BS 6161-12 |
| Data Storage | 999 measurements with timestamp |
| Interface | USB 2.0, Bluetooth 2.0 |
| Power | Two 1.5 V AA alkaline batteries (≈10,000 measurements) or USB bus power |
| Operating Temperature | 15–40°C, ≤85% RH (non-condensing at 35°C) |
| Dimensions | 155 × 73 × 48 mm |
| Weight | 400 g |
| Brand | KRÜSS |
|---|---|
| Origin | Germany |
| Model | FP8800 |
| Type | Automated Flame Photometer |
| Measurement Principle | Flame Atomic Emission Spectrometry (F-AES) |
| Simultaneous Channels | 5 independent, configurable for Na, K, Li, Ca, Ba, Mg |
| Display | 8.4" TFT touchscreen interface |
| Data Storage | Up to 999 measurement records |
| Throughput | Up to 300 measurements per hour |
| Compliance | cGMP/GLP, FDA 21 CFR Part 11 (audit trail, electronic signature support), DHCP & LIMS integration capable |
| Calibration Output | Tabular and graphical calibration curves |
| Safety | Integrated intelligent flame safety interlock system |
| Category | Optical Measurement Instrument — Flame Photometer |
| Brand | Labthink |
|---|---|
| Model | IG-200 |
| Measurement Geometry | 20° / 60° / 85° (Standard Single-Angle Configuration) |
| Measurement Range | 0–199.9 GU |
| Resolution | 0.1 GU |
| Repeatability | ±1 GU |
| Zero Drift | ≤0.5 GU / 30 min |
| Accuracy | ±1 GU |
| Light Source | Tungsten-Halogen Lamp (10,000 h lifetime) |
| Calibration Standard | Fused Quartz Reference Tile (Annual Drift < 0.3%) |
| Power Supply | 4×AA Ni-MH Rechargeable Batteries (9 V DC, 100 mAh) |
| AC Adapter Input | 220 V, 50 Hz |
| Operating Temperature | −25 °C to +40 °C |
| Battery Life | Up to 10 h continuous operation |
| Auto-Zero Compensation | Yes |
| Data Hold & USB Export | Yes |
| Compliance | JJG 696–2015 (China National Verification Regulation for Gloss Meters), ISO 2813, ASTM D523, GB/T 9754 |
| Brand | Labthink |
|---|---|
| Model | NG260 |
| Measurement Angles | 20°, 60°, 85° |
| Measurement Range | 0–199.9 GU |
| Resolution | 0.1 GU |
| Repeatability | ±1 GU |
| Zero Drift | ≤0.5 GU / 30 min |
| Accuracy | ±1 GU |
| Light Source | Tungsten Halogen Lamp (Lifespan ≥10,000 h) |
| Calibration Standard | Fused Quartz Reference Tile (Annual Stability <0.3%) |
| Power Supply | 4×AA Ni-MH Rechargeable Batteries (9 V DC, 100 mAh) |
| AC Adapter Input | 220 V, 50 Hz |
| Operating Temperature | –25 °C to +40 °C |
| Battery Life | Up to 10 h continuous operation |
| Auto-Zero Function | Yes |
| Data Hold & Low-Battery Indication | Yes |
| Compliance | GB/T 9754, ISO 2813, ASTM D523, ASTM D2457, JIS Z8741 |
| Brand | Labthink |
|---|---|
| Model | WGT-S |
| Origin | Shandong, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Automatic |
| Haze Range | 0–30.00% |
| Transmittance Range | 0–100.0% |
| Haze Repeatability | ±0.05% (when H ≤ 0.5%) |
| Transmittance Repeatability | ±0.5% |
| Light Source | C-illuminant (12 V DC, 50 W tungsten-halogen lamp + color temperature correction filter) |
| Sample Size | 50 mm × 50 mm (for films) |
| Aperture Dimensions | Input port Ø25 mm, Output port Ø21 mm |
| Detection Method | Collimated illumination, diffuse viewing, integrating sphere detection |
| Detector | Silicon photodiode with photopic luminosity function (V(λ)) correction |
| Compliance Standards | GB/T 2410, ASTM D1003–07 (Standard Test Method for Haze and Luminous Transmittance of Transparent Plastics), JIS K7105–1981 |
| Dimensions | 740 mm (L) × 270 mm (W) × 300 mm (H) |
| Net Weight | 21 kg |
| Power Supply | 220 V, 50 Hz |
| Brand | Labthink |
|---|---|
| Model | WGT-S |
| Origin | Shandong, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Automatic |
| Haze Range | 0–30.00% |
| Transmittance Range | 0–100.0% |
| Haze Repeatability | ±0.05% (for H ≤ 0.5%) |
| Transmittance Repeatability | ±0.5% |
| Light Source | C-illuminant (12 V DC, 50 W tungsten-halogen lamp + color temperature correction filter) |
| Sample Size | 50 mm × 50 mm (film) |
| Aperture Dimensions | Entrance Ø25 mm, Exit Ø21 mm |
| Detection System | Silicon photodiode with photopic luminosity function (V(λ)) correction |
| Integrating Sphere Geometry | Collimated Illumination / Diffuse Viewing |
| Compliance Standards | GB/T 2410, ASTM D1003–07 (reapproved 2013), JIS K7105–1981 |
| Dimensions | 740 mm (L) × 270 mm (W) × 300 mm (H) |
| Net Weight | 21 kg |
| Power Supply | 220 V, 50 Hz |
| Brand | Labthink |
|---|---|
| Model | WGT-S |
| Origin | Shandong, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Domestic |
| Type | Manual Operation |
| Haze Range | 0–30.00% |
| Transmittance Range | 0–100.0% |
| Haze Repeatability | ±0.05% (when H ≤ 0.5%) |
| Transmittance Repeatability | ±0.5% |
| Light Source | C-illuminant (12 V DC, 50 W tungsten-halogen lamp + color temperature correction filter) |
| Sample Port Diameter | Input Ø25 mm, Output Ø21 mm |
| Sample Holder | 50 mm × 50 mm film fixture |
| Detector | Silicon photodiode with photopic luminosity correction (V(λ) compliant) |
| Instrument Dimensions | 740 mm (L) × 270 mm (W) × 300 mm (H) |
| Net Weight | 21 kg |
| Power Supply | 220 V, 50 Hz |
| Standards Compliance | GB/T 2410, ASTM D1003–07 (reapproved 2013), JIS K7105–1981 |
| Brand | Lovibond (Tintometer) |
|---|---|
| Origin | United Kingdom |
| Model | TG268 |
| Type | Automatic Gloss Meter |
| Measurement Angles | 20°, 60°, 85° |
| Measurement Areas (mm) | 20°: 10×10, 60°: 9×15, 85°: 5×36 |
| Measurement Ranges | 20°: 0–2000 GU, 60°: 0–1000 GU, 85°: 0–160 GU |
| Resolution | 0.1 GU |
| Repeatability | ±0.1 GU (0–10 GU), ±0.2 GU (10–100 GU), ±0.2% GU (100–2000 GU) |
| Reproducibility | ±0.2 GU (0–10 GU), ±0.5 GU (10–100 GU), ±0.5% GU (100–2000 GU) |
| Geometry | CIE 1931 Standard Observer (2°), Illuminant C |
| Compliance | ISO 2813, ASTM D523, ASTM D2457, GB/T 9754 |
| Response Time | 1.0 s |
| Display | 3.5″ TFT capacitive touchscreen |
| Data Storage | 1,000 readings (Basic), 5,000 (Statistical & Continuous modes) |
| Interface | USB, RS-232 |
| Power | Rechargeable 3200 mAh Li-ion battery (up to 10,000 measurements per charge) |
| Operating Temperature | 0–40 °C |
| Storage Temperature | −20–50 °C |
| Relative Humidity | <85% RH (non-condensing) |
| Dimensions | 160 × 75 × 90 mm |
| Weight | 350 g |
| Software | OnShade QC Suite (GLP-compliant reporting, audit trail, export to CSV/PDF) |
| Brand | Lovibond (Tintometer) |
|---|---|
| Origin | United Kingdom |
| Model | TG268/60 Gloss Meter |
| Measurement Angles | 20° / 60° / 85° (TG268) |
| Compliance | ISO 2813, ASTM D 523, ASTM D 2457, GB/T 9754 |
| Measurement Area | 20°: 10 × 10 mm |
| 60° | 9 × 15 mm |
| 85° | 5 × 3 mm (TG268) |
| 60° | 9 × 15 mm (TG60) |
| Gloss Range | 20°: 0–2000 GU |
| 60° | 0–1000 GU |
| 85° | 0–160 GU (TG268) |
| Resolution | 0.1 GU |
| Repeatability | ±0.1 GU (0–10 GU), ±0.2 GU (10–100 GU), ±0.2% GU (100–2000 GU) — TG268 |
| Reproducibility | ±0.2 GU / ±0.5 GU / ±0.5% GU across ranges |
| Measurement Time | 1.0 s (TG268), 0.5 s (TG60) |
| Display | 3.5-inch TFT true-color capacitive touchscreen |
| Data Storage | Basic mode: 1,000 readings |
| Statistical & Continuous modes | 5,000 readings each |
| Interface | USB & RS232 |
| Power | 3200 mAh Li-ion battery (≥10,000 measurements per charge, ~8 h runtime) |
| Dimensions | 160 × 75 × 90 mm |
| Weight | 350 g |
| Operating Environment | 0–40 °C, <85% RH (non-condensing) |
| Storage | −20–50 °C |
| Standard Accessories | Calibration tiles (gloss standards), OnShade QC software, AC adapter, USB cable, user manual |
| Brand | Lovibond |
|---|---|
| Origin | United Kingdom |
| Model | TG60 |
| Measurement Angle | 60° |
| Compliant Standards | ISO 2813, ASTM D523, ASTM D2457, GB/T 9754 |
| Measuring Area | 9 mm × 15 mm |
| Gloss Range | 0–300 GU |
| Resolution | 0.1 GU |
| Repeatability | ±0.1 GU (0–10 GU), ±0.2 GU (10–100 GU), ±0.2% GU (100–300 GU) |
| Reproducibility | ±0.2 GU (0–10 GU), ±0.5 GU (10–100 GU), ±0.5% GU (100–300 GU) |
| Illuminant | CIE Standard Illuminant C |
| Observer Angle | 2° |
| Measurement Time | 0.5 s |
| Dimensions | 160 mm × 75 mm × 90 mm |
| Weight | 350 g |
| Display | 3.5-inch TFT capacitive touchscreen |
| Operating Temperature | 0–40 °C |
| Storage Temperature | −20–50 °C |
| Relative Humidity | <85% RH (non-condensing) |
| Power | Rechargeable 3200 mAh Li-ion battery (up to 10,000 measurements per charge) |
| Interface | USB & RS-232 |
| Data Storage | 1,000 readings (basic mode) |
| Software | OnShade QC software with GLP-compliant reporting and export functionality |
| Origin | Tianjin, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (PRC) |
| Model | MN60-C |
| Pricing | Available Upon Request |
| Brand | NIPPON DENSHOKU |
|---|---|
| Origin | Japan |
| Model | NDH8000 |
| Type | Automatic |
| Measurement Principle | Dual-beam compensated integrating sphere |
| Light Source | White LED |
| Sample Size Range | 30 mm × 30 mm to 210 mm × 297 mm (A4) |
| Haze Range | 0–100% |
| Total Luminous Transmittance Range | 0–100% |
| Haze Repeatability | ≤0.03% std. dev. (20 consecutive measurements) |
| Transmittance Repeatability | ≤0.03% std. dev. |
| Compliance Standards | JIS K7361, JIS K7136, JIS K7105, ASTM D1003, ISO 13468, ISO 14782 |
| Power Supply | 100–240 V AC, 50/60 Hz, 20 VA |
| Dimensions (Main Unit) | 340 mm (W) × 294 mm (D) × 473 mm (H) |
| Weight (Main Unit) | 14 kg |
| Display | 5.7-inch color LCD |
| Data Storage | 1,000 test records internal memory |
| USB Port | Host & device mode (CSV export via FAT32 USB flash drive) |
| Interface Options | RS-232C, parallel printer port |
| Operating Languages | English, Japanese |
| Calibration Reminder | Configurable due-date alert |
| Real-time Clock | Year/Month/Day/Hour/Minute/Second |
| Averaging | 2–99 cycles programmable |
| Optional Accessories | CU-11 film holder, CU-II test unit, 7-mm abrasion test attachment, thermal line dot printer, impact dot printer, PC control software |
| Brand | NIPPON DENSHOKU |
|---|---|
| Origin | Japan |
| Model | PG-II/II M |
| Measurement Angles | PG-II — single angle (20°, 45°, 60°, 75° or 85°) |
| Gloss Range | 0.1–2038 GU (20°), 0.1–1675 GU (45°), 0.1–1000 GU (60°), 0.1–378 GU (75°), 0.1–162 GU (85°) |
| Light Source | Tungsten lamp (5 V / 125 mA, ~5,000 h lifetime) |
| Aperture | 10.5 mm × 60 mm |
| Measurement Time | ~1 s |
| Repeatability | ±0.5 GU (standard deviation, 20 measurements at 10 s intervals) |
| Power | 9 V alkaline battery (1 pc) |
| Power Consumption | 300 mW (single-angle), 600 mW (triple-angle) |
| Dimensions | 150 mm × 49 mm × 80 mm |
| Weight | 420 g (net, battery excluded) |
| Compliance | JIS Z 7841, ASTM D523, ISO 2813 |
| Interface | RS-232C for remote control and data export |
| Brand | NIPPON DENSHOKU |
|---|---|
| Origin | Japan |
| Model | VG7000 |
| Product Type | Automatic |
| Haze Range | 0–100% |
| Transmittance Range | 0–100% |
| Haze Repeatability | ±0.01% |
| Transmittance Repeatability | ±0.05% |
| Measurement Angles | 20°, 45°, 60°, 75°, 85° |
| Aperture | 14 mm × 45 mm |
| Measurement Time (5-angle) | ~4 s |
| Power Supply | 100–240 V AC, 50/60 Hz |
| Power Consumption | 20 W |
| Operating Environment | 10–40 °C, 30–80% RH (non-condensing) |
| Dimensions | 483 mm (W) × 157 mm (D) × 240 mm (H) |
| Weight | ~13 kg |
| Brand | NIPPON DENSHOKU |
|---|---|
| Origin | Japan |
| Model | VG8000 |
| Measurement Angles | 20°, 45°, 60°, 75°, 85° |
| Gloss Range | 0.1–2038 GU (20°) to 0.1–162 GU (85°) |
| Aperture | 14 mm × 45 mm |
| Measurement Time | ≤1 s (single angle), ≤4 s (five angles) |
| Accuracy | ±0.1% after 30-min warm-up (vs. standard white tile) |
| Repeatability | ≤0.1% (20 measurements, 10-s interval, 23°C) |
| Operating Environment | 10–40°C, 30–80% RH (non-condensing) |
| Power Supply | 100–240 V AC, 50/60 Hz, 20 W |
| Dimensions | 483 × 157 × 240 mm (W×D×H) |
| Weight | ~13 kg |
| Compliance | ISO 8254-1, ISO 8254-3, JIS Z 8741, JIS P 8142, TAPPI T 480 |
| Brand | Photo Research |
|---|---|
| Origin | USA |
| Model | V-5HSC |
| Detection Principle | Filter-based tristimulus photometry conforming to CIE 1931 2° standard observer |
| Luminance Range | 0.01 to 6,000 cd/m² |
| Dynamic Range | 60,000:1 |
| Measurement Speed | Up to 30 readings per second |
| Spectral Matching f₁′ (CIE X/Y/Z) | 3.4% / 3.2% / 3.4% |
| Interface | RS232 with ASCII command protocol |
| Flicker Measurement | JEITA-compliant (built-in, no add-on required) |
| Display | Integrated high-contrast OLED screen |
| Power | Rechargeable Li-ion battery (≥8 hrs continuous operation) |
| Brand | Photo Research |
|---|---|
| Origin | USA |
| Model | PR-521 |
| Type | Automatic |
| Illuminance Range | 0.01–999,999 lx |
| Luminance Range | 0.001–999,999 cd/m² |
| Chromaticity Accuracy | ±0.002 in CIE 1931 xy |
| Correlated Color Temperature (CCT) Range | 1000–100,000 K |
| Display | Backlit capacitive touchscreen |
| Data Storage | SD card (up to 52,000 measurements) |
| Interface | USB 2.0 |
| Battery | Rechargeable Li-ion, 6 hours continuous operation |
| Compliance | NIST-traceable calibration, ISO/CIE-compliant photometric geometry |
| Brand | Photo Research |
|---|---|
| Origin | USA |
| Model | PR-705 |
| Type | Automated |
| Spectral Range | 380–1068 nm (PR-715 variant) |
| Minimum Measurable Spot Size | 0.02 mm |
| Field of View Options | Multiple selectable |
| Radiance Sensitivity | 0.003 cd/m² |
| Haze Measurement Range | 20% |
| Transmittance Measurement Range | 50% |
| Haze Repeatability | ±0.2% |
| Transmittance Repeatability | ±0.5% |
| Measurement Time | 50 ms per acquisition |
| Detector | Thermoelectrically Cooled Sealed InGaAs/Si CCD Array |
| Compliance | MIL-STD-461/810 (as configured for military night vision applications) |
| Brand | Photo Research |
|---|---|
| Origin | USA |
| Model Series | PR-805, PR-810, PR-880, PR-810L |
| Detection Principle | Photomultiplier Tube (PMT) with Precision Interference Filter Wheel Architecture |
| Luminance Range (PR-810L) | 1 × 10⁻⁶ to 5.184 × 10⁵ fL |
| Luminance Range (PR-880) | 1 × 10⁻⁴ cd/m² min |
| Luminance Range (PR-810) | 1 × 10⁻⁴ fL min |
| Luminance Range (PR-805) | 9 × 10⁻⁴ fL min |
| Field-of-View Options | 3°, 1°, 0.25°, 0.125° (PR-810 & PR-810L) |
| Dynamic Range | 9 × 10⁶:1 (PR-805/810), 9 × 10⁸:1 (PR-810L) |
| Built-in Rechargeable Battery | >12 h continuous operation |
| Calibration Traceability | NIST-traceable, internal reference source (PR-880) |
| Compliance | MIL-STD-461E (EMI), ANSI PH2.17, CIE S 014/E:2006, ISO/CIE 11664-2:2019 |
| Brand | Photo Research |
|---|---|
| Origin | USA |
| Model | PR-920 |
| Type | Automated Imaging Photometer |
| Luminance Range | Not specified in input |
| Chromaticity Accuracy | Enabled by CIE 1931 Standard Observer-matched filter set |
| Spatial Resolution | 1024 × 1024 pixel cooled CCD array |
| Measurement Capabilities | Luminance, Chromaticity, Luminance Uniformity, Emitter Shape & Distortion, Convergence, MTF (Modulation Transfer Function) |
| Optional Accessory | Motorized 5-axis translation stage for automated spatial scanning |
| Compliance | Designed to support ISO/CIE-compliant photometric and colorimetric measurement workflows |
| Repeatability | High repeatability for luminance and chromaticity (exact values not provided in source data) |
| Brand | Photo Research |
|---|---|
| Origin | USA |
| Model | PR805/810 |
| Power Supply | Rechargeable Li-ion battery (≥12 h continuous operation) |
| Display | Full-color capacitive touchscreen |
| Lens | Standard 75 mm focal length (measurement distance: 355 mm to infinity) |
| Minimum Luminance | PR810 — 0.0001 fL (0.00034 cd/m²) |
| Apertures | PR805 — 10 fixed apertures |
| Neutral Density Filter Turret | 3-decade attenuation (10×, 100×, 1000×) |
| Dynamic Range | >9,000,000:1 |
| Interface | USB Virtual COM port (RS-232 emulation), optional Class 1 Bluetooth (100 m range) |
| Data Storage | Internal memory + SD card slot |
| Compliance | Designed for ASTM E308, CIE 15:2018, ISO/CIE 11664, USP <1033>, FDA 21 CFR Part 11–ready software integration |
| Brand | Photo Research |
|---|---|
| Origin | USA |
| Model | PR905 |
| Sensor Resolution | 1024 × 1024 pixels |
| Photopic V(λ) Filter Compliance | CIE 1931 Standard Observer |
| Standard Lens | 50 mm focal length |
| Optional Lenses | High-resolution telecentric and wide-angle optics |
| Optional ND Filters | OD 0.3 to OD 3.0 (logarithmic attenuation) |
| Software | VideoWin v5.x with real-time exposure optimization, ROI-based analysis, and Excel export capability |
| Compliance | Meets CIE Publication No. 15, ISO/CIE 11664-1:2016 (colorimetry), and ASTM E308-22 (computing tristimulus values) |
| Data Output | Luminance (cd/m²), Chromaticity (CIE x,y or u′,v′), Uniformity (% deviation), Contrast Ratio (luminance ratio), Defect localization map |
| Brand | Photo Research |
|---|---|
| Origin | USA |
| Model | PR-670 |
| Spectral Resolution | 1.56 nm/pixel |
| Detector Array | 256-element CCD |
| Field-of-View Options | 1°, 0.5°, 0.25°, 0.125° (motorized aperture selection) |
| Luminance Sensitivity | 0.01 fL (3.4 × 10⁻⁵ cd/m²) |
| Battery Life | Up to 12 hours (rechargeable Li-ion) |
| Control Interface | Local keypad and remote TTL/RS-232/Ethernet |
| Compliance | NIST-traceable calibration, supports CIE 1931 XYZ, CIE 1976 u’v’, and CIE 2015 photobiological safety weighting functions |
| Brand | Photo Research |
|---|---|
| Origin | USA |
| Model | PR-680 |
| Type | Portable, Automatic |
| Luminance Range | 0.003 to 10⁸ cd/m² |
| Spectral Resolution | 0.9 nm (FWHM) |
| Wavelength Range | 380–780 nm |
| CIE Standard Observer | 2° and 10° |
| Compliance | NIST-traceable calibration, ISO/CIE-compliant spectral measurement architecture |
| Measurement Modes | Spectral Radiance, Illuminance, Luminance, Chromaticity (x,y & u’v’), Correlated Color Temperature (CCT), Dominant Wavelength, Color Rendering Index (CRI), TM-30 (Rf, Rg) |
| Data Interface | USB 2.0, RS-232, Ethernet |
| Software Compatibility | PR-680 Control Software, SpectraWin v5.0+, supports ASTM E308, CIE 15:2018, IEC 61747-1, ISO 13406-2, VESA FPDM 2.0 |
| Brand | Radiant Zemmax |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Models | IS-LI, IS-VA, IS-SA |
| Pricing | Available Upon Request |
| Brand | Radiant Zemax |
|---|---|
| Origin | USA |
| Model | NFMS0400 / FPMS0400 |
| Type | Near-Field Measurement System for Luminaires |
| Compliance | Supports IESNA LM-79, CIE S 025, ISO/CIE 19476 |
| Software Platform | TrueTest™ v7.0+ |
| Detector Options | ProMetric® Y-series (luminance) and I-series (chromaticity) imaging photometers |
| Angular Range | ±90° in azimuth, ±90° in elevation |
| Spatial Resolution | Up to 9M pixels per image |
| Dynamic Range | ≥1,000,000:1 (typical with HDR acquisition) |
| Calibration Traceability | NIST-traceable luminance & chromaticity standards |
| Brand | Radiant Vision Systems (formerly Radiant Zemax) |
|---|---|
| Origin | USA |
| Model Series | ProMetric |
| Sensor Types | 10-bit, 14-bit, and 16-bit scientific-grade cooled CCD/CMOS imagers |
| Dynamic Range | Up to 1,000,000:1 (depending on model and configuration) |
| Spatial Resolution | Up to 29 megapixels (IC-PMIXX) |
| Measurement Capabilities | Luminance, Illuminance, Luminous Intensity, Luminous Flux, Radiance, Irradiance, Radiant Intensity, Radiant Flux, CIE x,y & u',v' Chromaticity, Correlated Color Temperature (CCT) |
| Compliance | NIST-traceable calibration, ISO/CIE-compliant photometric and colorimetric response |
| Software Platform | TrueTest™ and PM-Series™ software with FDA 21 CFR Part 11–compliant audit trail options |
| Interface | GigE Vision, USB3, or Camera Link (model-dependent) |
| Brand | Radiant Zemax |
|---|---|
| Origin | USA |
| Model | SIG300 / SIG310 / SIG400 |
| Application Scope | Near-field luminance, chromaticity, and angular intensity distribution measurement of LEDs, lamp modules, and compact light sources |
| Compliance Framework | Supports ASTM E308, CIE 127, IES LM-79, ISO/CIE 11664 (colorimetry), and FDA/ISO 13485-aligned quality documentation workflows |
| Software Integration | Fully compatible with ProSource® v10+ for RSM generation, ray set export (IES, EULUMDAT, ASAP, LightTools, TracePro), GLP/GMP audit trail logging, and 21 CFR Part 11–compliant user access control |
| Brand | Konica Minolta |
|---|---|
| Origin | Japan |
| Model | Rhopoint IQ-S |
| Instrument Type | Handheld, Automatic |
| Haze Range | 0–90% |
| Transmittance Range | 0–100% |
| Haze Repeatability | ±0.2% |
| Transmittance Repeatability | ±0.2% |
| Measurement Angles | 20°, 60°, 85° (angle-selectable per surface finish) |
| Key Metrics | Gloss, Peak Gloss, Reflectance Haze, Reflectance Image Quality (RIQ), DOI (Distinctness of Image) |
| Brand | SOLY |
|---|---|
| Origin | Shanghai, China |
| Model | SLY100 |
| Product Type | Automatic |
| Haze Range | 0–100% |
| Total Transmittance Range | 0–100% |
| Haze Repeatability | ±0.1% |
| Transmittance Repeatability | ±0.1% |
| Compliance Standards | ASTM D1003, ASTM D1044, ISO 13468, ISO 14782, GB/T 2410 |
| Illuminants | A, C, D65 (for haze) |
| Display | 7-inch Android touchscreen interface |
| Sample Chamber | Open-access, dual-orientation (horizontal/vertical) |
| Software | PC-based analysis suite with report generation, audit trail, and data export (CSV, PDF, XML) |
