| Brand | NIKON |
|---|---|
| Origin | Japan |
| Model | E200 Trinocular |
| Optical System | CFI60 Infinity-Corrected |
| Observation Head | Trinocular (E2-TF), 30° Inclination, Interpupillary Distance 47–75 mm |
| Eyepieces | CFI 10×/20 mm Field Number (FN) |
| Objective Lenses | CFI E Plan Achromat 4×, 10×, 40×, 100× (anti-fungal coated) |
| Nosepiece | Inclined 4-position Revolving Nosepiece |
| Condenser | E2 Abbe Condenser, NA 1.25 |
| Focusing Mechanism | Coaxial Coarse/Fine Focus, Fine Focus Graduation 2 µm, Coarse Travel 37.7 mm/rev, Fine Travel 0.2 mm/rev |
| Stage | Rectangular Mechanical Stage, 216 × 150 mm, Travel Range 78 × 54 mm |
| Illumination | LED Light Source (60,000 hr lifetime), Constant CCT Across Intensity Range, IR-Free, Low Heat & Power Consumption |
| Anti-Fungal Protection | Internal Anti-Mold Coating + Desiccant Mold-Prevention Strips (validated for 3 years at 30°C / 80% RH) |
| Ergonomics | Adjustable Tilting Eyepiece Tube (±30°), Height-Optimized Stage Controls, Low-Profile Knob Placement |
| Compatibility | CFI60 Objective Mount, Full Eclipse Series Accessory Ecosystem (Phase Contrast, Fluorescence, Polarization, Digital Imaging) |
| Brand | NIKON |
|---|---|
| Origin | Japan |
| Model | E100 |
| Microscope Type | Upright Biological Microscope |
| Eyepiece Configuration | Binocular |
| Optical System | CFI Infinity-Corrected Optics |
| Illumination | High-Efficiency LED (60,000 hr lifetime) |
| Objective Series | CFI BE Plan Achromat |
| Condenser | Abbe Condenser, NA 1.25 |
| Focus Mechanism | Coaxial Coarse/Fine Adjustment (2 µm fine graduation) |
| Stage | Dual-layer Mechanical Stage (155 × 134 mm) |
| Eyepiece Inclination | 30° |
| Interpupillary Distance Range | 47–75 mm |
| Eye-point Adjustment Range | 34 mm |
| Optional Accessories | Phase Contrast Rings (10×, 40×, 100×), Darkfield Annuli (10×, 20×, 40×), Filter Holder (33 mm) |
| Brand | NIKON |
|---|---|
| Origin | Japan |
| Model | E100 Trinocular |
| Optical System | CFI Infinity-Corrected |
| Observation Head | E2-TF Trinocular, 30° Inclination, Interpupillary Distance 47–75 mm |
| Eyepieces | CFI E 10×/18 (standard), optional CFI E 15×/12 |
| Objective Turret | Quadruple Nosepiece |
| Objectives | CFI BE Plan Achromat 4×, 10×, 40×, 100× (oil), optional 20×, 60× |
| Condenser | Abbe Condenser, NA 1.25, 33 mm Filter Holder |
| Focusing | Coaxial Coarse/Fine Focus, Fine Focus Graduation 2 µm, Coarse Travel 37.7 mm/rev, Fine Travel 0.2 mm/rev, Total Travel 22 mm |
| Stage | Double-Layer Mechanical Stage, 155 × 134 mm |
| Illumination | High-Efficiency White LED (60,000 h lifetime), Constant CCT across intensity range, IR-free, low heat, low power consumption |
| Accessories | Phase Contrast Annuli (10×, 40×, 100×), Darkfield Rings (10×, 20×, 40×), Pointer, Mirror, Power Cord Clip, Protective Packaging (Aluminum Case) |
| Anti-Fungal Treatment | Applied to eyepieces, objectives, and observation tube |
| Brand | Nikon |
|---|---|
| Origin | Japan |
| Microscope Type | Upright Biological Microscope |
| Configuration | Binocular |
| Illumination | High-Efficiency White LED (60,000 hr lifetime) |
| Optical System | CFI60 Infinity-Corrected |
| Eyepiece Field Number | 20 mm (10×), 12 mm (15×) |
| Objective Mount | Inclined Quadruple Nosepiece |
| Condenser | E2 Abbe Condenser, NA 1.25 |
| Focusing | Coaxial coarse/fine focus, fine focus graduation: 2 µm, coarse travel per revolution: 37.7 mm, fine travel per revolution: 0.2 mm |
| Stage | Rectangular mechanical stage, 216 × 150 mm, 78 × 54 mm travel |
| Ergonomic Tilting Eyepiece Tube | 30° inclination, interpupillary adjustment 47–75 mm, eyepoint height adjustable up to +34 mm |
| Anti-Fungal Protection | Integrated anti-mold coating and desiccant strips, validated for continuous operation at 30°C / 80% RH for ≥36 months |
| Compliance | Designed to support ISO/IEC 17025-compliant documentation workflows |
