| Brand | Tianfeng |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Equipment Type | Integrated Circulating Chiller |
| Cooling Method | Water-Cooled |
| Rated Refrigeration Capacity | 9.43 kW (8,109.8 kcal/h) |
| Temperature Control Range | 5–30 °C |
| Temperature Stability | ±0.1 °C (typical, dependent on load and ambient conditions) |
| Circulating Pump Pressure | 0–2 kgf/cm² |
| Circulating Flow Rate | 0–60 L/min |
| Reservoir Volume | 60 L |
| Input Power | 3.3 kW |
| Power Supply | 220 V, 50 Hz |
| Compressor Type | Scroll Compressor |
| Safety Protections | High/Low Pressure Switch, Overcurrent Protection, Compressor Overheat Protection, Overtemperature Alarm |
| Dimensions (L×W×H) | 550 × 880 × 1160 mm |
| Net Weight | Approx. 125 kg |
| Noise Level | ≤72 dB(A) |
| Construction | Stainless Steel Reservoir & Pump, IP54 Electrical Enclosure |
| Compliance | ISO 9001:2000 Certified Design & Manufacturing |
| Brand | Tianfeng |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Product Type | Integrated Circulating Chiller |
| Cooling Method | Water-Cooled |
| Temperature Control Range | 0–40 °C |
| Refrigeration Capacity | 300–9000 W |
| Temperature Stability | ±0.1 °C |
| Circulation Pump Pressure | 2.0 bar |
| Circulation Flow Rate | 38 L/min |
| Reservoir Volume | 5–550 L |
| Operation Mode | Continuous Duty |
