| Brand | Thermo Fisher Scientific |
|---|---|
| Origin | Czech Republic |
| Model | Helios 5 DualBeam |
| Landing Voltage Range | 20 eV – 30 keV |
| SEM Resolution | Down to 0.6 nm @ 15–30 keV (depending on configuration) |
| FIB Current Range | 1 pA – 100 nA |
| Ion Acceleration Voltage | 500 V – 30 kV |
| Stage Travel | Up to 150 × 150 × 10 mm (X/Y/Z, model-dependent) |
| Automated TEM Lamella Preparation | Supported (via AutoTEM 5 software) |
| STEM Imaging Capability | Integrated (sub-nm resolution at 30 keV) |
| Compliance | Designed for GLP/GMP environments |
| Brand | Thermo Fisher |
|---|---|
| Origin | Czech Republic |
| Model | Talos F200i S/TEM |
| Accelerating Voltage | 20–200 kV |
| TEM Line Resolution | ≤0.10 nm |
| TEM Information Resolution | ≤0.12 nm |
| STEM Resolution | ≤0.16 nm |
| LACBED Convergence Angle | ≥100 mrad |
| Diffraction Angle | up to 24° |
| EDS Configuration | Side-mounted, retractable |
| Electron Source | High-brightness field emission gun (FEG) |
| Specimen Stage Z-Travel (standard holder) | ±0.375 mm |
| Tilt Range (3D tomography holder) | ±90° |
| Specimen Drift | ≤0.5 nm/min |
| Camera | 4k × 4k Ceta 16M CMOS |
| Brand | Thermo Fisher Scientific |
|---|---|
| Origin | Czech Republic |
| Model | Helios 5 Laser PFIB |
| Integrated Beams | SEM + Plasma FIB (Xe⁺) + Femtosecond Laser (1030 nm / 515 nm) |
| Laser Pulse Width | <280 fs (1ω), <300 fs (2ω) |
| Laser Repetition Rate | 1 kHz – 1 MHz |
| Laser Spot Size | 15 µm |
| Maximum 3D Volume | 2000 × 2000 × 1000 µm³ |
| Plasma FIB Beam Current | ~1 mA (equivalent), Cutting Current: 74 µA |
| Beam Co-location Accuracy | <250 nm at WD = 4 mm |
| Laser Safety Class | Class 1 Enclosed System |
| Software | Integrated Laser Control, Automated 3D Serial Sectioning Workflow, EBSD-Coupled 3D Reconstruction Module, Scriptable Laser Programming Interface |
| Brand | GATAN |
|---|---|
| Origin | USA |
| Model | SOLARUS (950) |
| RF Power | 50 W with auto-matching |
| Vacuum System | 70 L/s turbomolecular pump + dual-stage diaphragm pump |
| Base Pressure | 5 × 10⁻⁶ Torr |
| Operating Pressure | 400 mTorr |
| Chamber Dimensions | 3.5" diameter × 2.0" depth |
| Gas Control | Triple independent MFCs (H₂, O₂, Ar) |
| Cleaning Cycle Time | <2 min (pump-down + plasma treatment + vent) |
| Sample Loading | Dual front ports for TEM/SEM sample holders + top port for >25 TEM grids or SEM stages |
| Plasma Observation | Integrated viewport |
| Compliance | Designed for GLP/GMP-aligned lab environments |
| Brand | Thermo Fisher Scientific |
|---|---|
| Origin | Czech Republic |
| Model | Apreo ChemiSEM |
| Instrument Type | Floor-standing High-Resolution FE-SEM |
| Electron Gun | Schottky Thermal Field Emission |
| Secondary Electron Resolution | 0.7 nm @ 30 kV |
| Backscattered Electron Resolution | 0.7 nm @ 30 kV |
| Magnification Range | 50× – 1,000,000× |
| Accelerating Voltage | 200 V – 30 kV |
| Landing Energy Range | 20 eV – 30 keV |
| Maximum Sample Size at 10 mm WD | 3 mm (min. mag. 29×) |
| Chamber Ports | 18 |
| Stage Travel | X = 110 mm, Y = 110 mm, Z = 65 mm, Tilt = −15° to +90°, Rotation = 360° continuous |
| Standard Detector System | Trinity In-lens Detection System (T1, T2, T3), TD, DBS |
| Optional Detectors | DBS-GAD, Low-Vacuum SE Detector, STEM 3+ Segmented Detector (BF/DF/HADF/HAADF), IR CCD, Thermo Scientific™ Nav-Cam™ Navigation Camera |
| Brand | Gatan |
|---|---|
| Origin | USA |
| Model | Alto 2500 |
| Vacuum Performance | <1×10⁻⁶ mbar (preparation chamber) |
| Operating Temperature Range | –190 °C to +50 °C (sample stage) |
| Cooling Method | Liquid nitrogen–cooled cryo-stage & subcooled nitrogen gas–cooled SEM stage |
| Cryo-Stage Stability | ±1 °C |
| Imaging Compatibility | Field-emission SEM (FE-SEM), FIB-SEM, and dual-beam systems |
| Brand | Gatan |
|---|---|
| Origin | USA |
| Model | SmartEMIC |
| Price | $120,000 |
| Category | Electron Microscope Accessories & Peripherals |
| Brand | Thermo Fisher Scientific |
|---|---|
| Origin | Czech Republic |
| Model | Quattro |
| Instrument Type | Floor-standing SEM |
| Electron Source | Cold Field-Emission Gun (CFEG) |
| Magnification Range | 6× to 2,500,000× |
| Accelerating Voltage | 200 V to 30 kV |
| Landing Voltage | 20 eV to 30 keV (with beam deceleration option) |
| Probe Current | 1 pA to 200 nA (continuously adjustable) |
| Secondary Electron Resolution | 1.3 nm @ 30 kV (SE, low-vacuum mode) |
| Backscattered Electron Resolution | 2.5 nm @ 30 kV (BSE, high-vacuum mode) |
| Working Distance for EDS | 10 mm |
| EDS Take-off Angle | 35° |
| Chamber Width | 340 mm |
| Number of Available Ports | 12 (including 3 EDS-compatible ports, two at 180° opposition) |
| Stage Type | 5-axis motorized eucentric stage |
| XY Travel (Quattro C / Quattro S) | 55 × 55 mm / 110 × 110 mm |
| Z Travel | 65 mm |
| Tilt Range | –15° to +90° |
| Rotation | Continuous 360° |
| Maximum Sample Height (from eucentric height) | 85 mm |
| Max Sample Weight | 5 kg (at 0° tilt) |
| Max Sample Diameter (full rotation compatible) | 122 mm |
| Detector Options | In-chamber Everhart-Thornley detector (ETD), Low-Vacuum Detector (LVD), Gas Secondary Electron Detector (GSED), Integrated STEM-in-SEM (WetSTEM™), IR-CCD chamber camera, Nav-Cam™ optical navigation camera |
| Software Platform | 64-bit Windows-based GUI with multi-view display, montage navigation, undo/redo functionality, joystick and multifunction control panel support |
| Brand | ROCK |
|---|---|
| Origin | Hong Kong, China |
| Model | MaipSCAN |
| Instrument Type | Floor-standing SEM |
| Electron Source | Tungsten Filament |
| Secondary Electron Resolution | 3.0 nm @ 30 kV (SE and W) |
| Magnification Range | 7× – 1,000,000× |
| Accelerating Voltage | 0.2 – 30 kV |
| Backscattered Electron Resolution | 4.0 nm @ 30 kV (VP mode with BSD) |
| Brand | Thermo Fisher Scientific |
|---|---|
| Origin | Czech Republic |
| Model | Scios 2 DualBeam |
| Electron Source | Schottky Field Emission Gun |
| STEM Resolution | 0.8 nm at 30 kV (WD = 7 mm) |
| SEM Resolution | 1.6 nm at 1 keV, 1.4 nm at 1 keV with beam deceleration |
| Ion Beam Resolution | 3.0 nm at 30 kV |
| Ion Beam Current Range | 1.5 pA – 65 nA |
| Electron Beam Current Range | 1 pA – 400 nA |
| Acceleration Voltage (e-beam) | 200 V – 30 kV |
| Landing Voltage (e-beam) | 20 eV – 30 kV |
| Acceleration Voltage (ion-beam) | 500 V – 30 kV |
| Stage | 5-axis motorized, X/Y = 110 mm, Z = 65 mm, tilt = −15° to +90°, rotation = 360° |
| Maximum Sample Diameter | 110 mm |
| Maximum Sample Height (at full X/Y rotation) | 85 mm |
| Maximum Sample Mass | 5 kg |
| Chamber Ports | 21 |
| Chamber Inner Width | 379 mm |
| Integrated Detectors | In-lens ETD, T1 (in-lens BSE), T2 (in-lens SE), optional T3 (in-lens SE), DBS (segmented solid-state BSE), ICE (ion conversion & electron detector), IR-CCD, Nav-Cam+™ optical navigation camera |
| Brand | Gatan |
|---|---|
| Origin | USA |
| Model | C1000 |
| Temperature Range | –185 °C to +400 °C (model-dependent) |
| Cooling Medium | Liquid Nitrogen |
| Sample Diameter | 10 mm |
| Cooling Time | <10 min (RT to –185 °C) |
| Temperature Stability | ±0.5 °C |
| Tilt | 45° |
| Rotation | ±5° |
| Compatibility | Field-emission, standard, and environmental SEMs |
| Brand | Thermo Fisher |
|---|---|
| Origin | Czech Republic |
| Model | Prisma E SEM |
| Instrument Type | Floor-standing SEM |
| Electron Source | Tungsten Filament |
| Secondary Electron Resolution | 3.0 nm @ 30 kV (SE), 8.0 nm @ 3 kV (SE) |
| Backscattered Electron Resolution | 4.0 nm @ 3 kV (BSE), 10 nm @ 3 kV (SE) |
| Accelerating Voltage | 200 V – 30 kV |
| Magnification Range | 5× – 1,000,000× |
| Low Vacuum Range | up to 130 Pa |
| ESEM Mode Pressure | up to 2600 Pa (H₂O), 4000 Pa (N₂) |
| Sample Chamber Width | 340 mm |
| Expandable Ports | 12 total, including 3 EDS ports (2 at 180° opposing positions) |
| Stage | 5-axis motorized eucentric stage (X=110 mm, Y=110 mm, Z=65 mm, T=–15° to 90°, R=360° continuous) |
| Standard Detectors | ETD (high-vacuum SE), LVD (low-vacuum SE), GSED (ESEM SE), IR CCD camera in chamber |
| Brand | Gatan |
|---|---|
| Origin | USA |
| Model | ALTO 1000 |
| Sample Temperature Range | −210 °C (LN₂ slush) to +50 °C |
| SEM Cold Stage Operating Range | −185 °C to +50 °C |
| Cold Stage Stability | ±1 °C |
| Pre-chamber Base Pressure | <1×10⁻³ mbar |
| Integrated LN₂ Slush Station | Yes (ALTO 1000D/E) |
| Vacuum Transfer Device (VTD) | Yes (ALTO 1000D/E) |
| Cryo-Fracture Knife | Standard |
| Sputter Coater | Optional (ALTO 1000E, magnetron-based, multi-metal compatible) |
| Control Interface | Dedicated compact keypad with real-time parameter display |
| Interlock System | Full electro-mechanical interlocking with SEM communication |
| Brand | Thermo Fisher |
|---|---|
| Origin | Czech Republic |
| Model | Talos L120C TEM |
| Accelerating Voltage | 120 kV |
| Point Resolution | < 0.37 nm |
| Line Resolution | 0.204 nm |
| Magnification Range (TEM) | 25× – 650,000× |
| Magnification Range (STEM) | 200× – 2.2 M× |
| Alpha Tilt Range (Standard Holder) | −90° to +90° |
| STEM HAADF Resolution | ≤ 1.0 nm |
| Detector | 4k × 4k Ceta CMOS Camera |
| Brand | Gatan |
|---|---|
| Origin | USA |
| Model | MonoCL4 |
| Manufacturer | Gatan, Inc. |
| Detector Type | Parabolic Mirror Collection with Direct-Coupled Czerny-Turner Monochromator |
| Spectral Range | 185–850 nm |
| Spectral Resolution | Adjustable via Micrometer Slit (Typical FWHM < 1.5 nm at 500 nm) |
| Collection Efficiency | Optimized via Diamond-Turned Parabolic Mirror (75 mm retractable stroke) |
| Detection | PMT with Integrated Preamplifier |
| Software | DigitalMicrograph® with MonoCL4 Plugin |
| Compliance | Fully Compatible with SEM/TEM/EPMA Platforms |
| Brand | Thermo Fisher |
|---|---|
| Origin | Czech Republic |
| Model | Talos F200X S/TEM |
| Accelerating Voltage | 200 kV (standard configuration) |
| Resolution | <0.12 nm TEM point resolution, <0.16 nm STEM HAADF resolution |
| EDS System | Super-X with four integrated silicon drift detectors (SDDs) |
| Camera | Ceta 16M CMOS, 25 fps at 512 × 512 |
| Stage | Piezo-driven high-precision stage with sub-nanometer stability |
| Software | Thermo Scientific Velox S/TEM Platform (FDA 21 CFR Part 11 compliant audit trail option available) |
| Brand | Gatan |
|---|---|
| Origin | USA |
| Model | PECS II 685 |
| Ion Source | Two rare-earth magnet-equipped Penning ion guns (maintenance-free) |
| Beam Energy Range | 100 eV – 8.0 keV |
| Beam Current Density | 10 mA/cm² (peak) |
| Beam Diameter Control | Via gas flow or discharge voltage |
| Sample Capacity | Ø ≤ 32 mm, H ≤ 15 mm |
| Polishing Angle Adjustment | ±10° per gun, independently adjustable |
| Dual-Beam Modulation | Single- or dual-beam angular modulation |
| Sample Rotation | 1–6 rpm, continuously variable |
| Cooling | Liquid nitrogen-cooled stage |
| Vacuum System | 80 L/s turbomolecular pump + dual-stage diaphragm pump |
| Base Pressure | ≤ 5 × 10⁻⁶ Torr |
| Operating Pressure | ≤ 8 × 10⁻⁵ Torr |
| Vacuum Gauge | Cold-cathode gauge (main chamber), solid-state gauge (foreline) |
| Load Lock | Whisperlok™ airlock technology (< 1 min exchange, no main chamber vent) |
| User Interface | 10-inch color touchscreen with recipe-based operation |
| Compliance | Designed for GLP-compliant lab environments |
| Brand | Thermo Fisher |
|---|---|
| Origin | Czech Republic |
| Model | Apreo 2 |
| Instrument Type | Floor-standing SEM |
| Electron Gun | Schottky Field Emission |
| Microscope Class | Ultra-High-Resolution FE-SEM |
| Magnification Range | 5× to 1,000,000× |
| Accelerating Voltage | 200 V – 30 kV |
| Maximum Sample Width | 340 mm (horizontal chamber dimension) |
| Expandable Chamber Ports | 12 total, including 3 EDS-compatible ports (2 at 180° opposing positions) |
| Stage | 5-axis motorized eucentric stage (X = 110 mm, Y = 110 mm, Z = 65 mm, Tilt = −15° to +90°, Rotation = 360° continuous) |
| Standard Detectors | In-chamber Everhart-Thornley SE detector (ETD), in-column backscattered electron detector (T1), in-column secondary electron detector (T2) |
| Brand | Opton |
|---|---|
| Origin | Germany |
| Distributor Type | Authorized Distributor |
| Import Status | Imported |
| Model | AMICS |
| Electron Gun | Tungsten Filament |
| Secondary Electron Resolution | 3.0 nm @ 30 kV (SE, W) |
| Magnification Range | 5× – 1,000,000× |
| Accelerating Voltage | 0.2–30 kV |
| Backscattered Electron Resolution | 4.0 nm @ 30 kV (VP with BSD) |
| Minimum Detectable Mineral Grain Size | 1 µm |
| Typical Measurement Time (30 mm diameter sample) | 15 min |
| Mineral Database | >2,000 reference minerals |
| Stage | High-precision 5-axis motorized 9-pin stage |
| EDS Detector Compatibility | Silicon Drift Detector (SDD), liquid-nitrogen-free cryogenic cooling, ultra-fast pulse processing (e.g., Bruker QUANTAX) |
| Brand | Gatan |
|---|---|
| Origin | USA |
| Model | 697 Ilion II |
| Ion Gun Type | Dual Penning-type with Triode (Cathode/Anode/Focusing Electrode) Construction |
| Beam Energy Range | 100 eV – 8 keV |
| Beam Current Control | 0–100 mA per gun via Mass Flow Controller |
| Beam Angle Adjustment | ±10° per gun, 0.1° incremental resolution |
| 扇形抛光角 | ��Sector Polish Angle）: Programmable 10°–90° |
| Polishing Rate | Up to 300 µm/h (on Si at 8 keV) |
| Vacuum Base Pressure | 5×10⁻⁶ Torr |
| Operating Pressure | 8.5×10⁻⁵ Torr |
| Pumping System | 80 L/s Turbo-Molecular Pump + Dual-Stage Diaphragm Pump |
| Sample Stage Rotation | 0.5–6 rpm, continuously adjustable |
| Cryogenic Stage | Liquid Nitrogen-cooled, down to −120 °C |
| Integrated Imaging | Digital Zoom Microscope (300×–2200×), real-time acquisition via Gatan DigitalMicrograph® software |
| Sample Exchange Time | < 60 s via WhisperLock™ pneumatic airlock |
| Ion Source Lifetime | > 30,000 hours, maintenance-free operation |
| Brand | Gatan |
|---|---|
| Origin | USA |
| Model | Murano 525 |
| Temperature Range | Ambient to 950 °C |
| Max Sample Size | 9 mm × 4.5 mm × 1.5 mm (with thermal shield) |
| Heating/Cooling Rate | >100 °C/min |
| Temperature Stability | ±0.5 °C |
| Temperature Control Accuracy | ±0.5 °C |
| Working Distance | 10 mm (with shield), 12.5 mm (without shield) |
| Brand | Thermo Fisher |
|---|---|
| Origin | Netherlands |
| Model | Axia ChemiSEM |
| Instrument Type | Floor-standing Conventional SEM |
| Electron Source | Pre-aligned Tungsten Filament |
| Secondary Electron (SE) Resolution | 3.0 nm @ 30 kV (HV), 8.0 nm @ 3 kV (HV) |
| Backscattered Electron (BSE) Resolution | 7.0 nm @ 3 kV (HV, decelerated mode) |
| Magnification Range | 5× to 1,000,000× |
| Accelerating Voltage | 200 V – 30 kV |
| Probe Current | Up to 2 µA, continuously adjustable |
| Low Vacuum Mode | Up to 150 Pa |
| Working Distance for EDS | 10 mm |
| EDS Take-off Angle | 35° |
| Chamber Internal Width | 280 mm |
| Number of Ports | 10 |
| Stage | 5-axis motorized (X=120 mm, Y=120 mm, Z=55 mm, Tilt=–15° to +90°, Rotation=360° continuous) |
| Max Sample Dimensions | 240 × 280 × 128 mm³ |
| Max Sample Weight | 10 kg |
| Detectors | In-chamber IR navigation camera, Nav-Cam+™ color optical camera, ETD (Everhart-Thornley SE detector), retractable BSED, TrueSight X EDS with ChemiSEM technology |
| Control System | Windows 10 OS, 24″ LCD display (1920×1200), customizable GUI supporting quad-image real-time display, full Undo/Redo functionality |
| Origin | USA |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | MICROTEST 2000E |
| Price Range | USD 135,000 – 205,000 |
| Key | Origin: USA |
|---|---|
| Manufacturer | Deben Ltd. |
| Distributor | Optosky Co., Ltd. |
| Type | Imported |
| Model | MICROTEST |
| Load Capacity Options | 200 N, 300 N, 2000 N, 5000 N |
| Strain Rate Range | 5 µm/min – 6 mm/min |
| Force Sensor Resolution | Down to 2 N |
| Bending Configurations | Horizontal 3-point & 4-point |
| EBSD-Compatible Versions | MICROTEST2000ES/EW, MICROTEST5000S/W |
| Thermal Options | RT, Heated (EH2000/H5000), Water-Cooled (MICROTEST2000W/5000W) |
| Software | Real-time stress–strain plotting with threshold-triggered acquisition and synchronized image–data capture |
Show next
