| Brand | SHNTI |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Product Category | Imported |
| Model | SN-LDE |
| Pricing | Upon Request |
| Frame Dimensions | 5×5 mm, 7.5×7.5 mm, or 10×10 mm |
| Window Aperture | 1.0×1.0 mm to 5.0×5.0 mm (square) |
| Si₃N₄ Membrane Thickness | 50–200 nm (custom 30–500 nm, MOQ 100 pcs) |
| Frame Thickness | 200 µm, 381 µm, or 525 µm |
| Surface Roughness | <1 nm RMS |
| Max Operating Temperature | 1000 °C |
| Vacuum Rating | ≥1 atm differential pressure (dependent on membrane thickness & aperture size) |
| Chemical Stability | Inert, compatible with plasma, glow discharge, and mild chemical cleaning (no ultrasonication) |
