| Brand | Alpha Plasma |
|---|---|
| Origin | Germany |
| Model | Q240 |
| Plasma Source | 2.45 GHz microwave, 1200 W |
| Chamber | Quartz, Ø240 mm × 460 mm (21 L), max. 200 mm wafer capacity |
| Dimensions (L×W×H) | 760 × 775 × 775 mm |
| Gas Control | 3-channel digital MKS mass flow controllers |
| Vacuum Door | Drawer-type with UV/microwave-shielded viewport |
| Human-Machine Interface | 10.4" touchscreen GUI, Windows CE OS |
| Brand | Alpha Plasma |
|---|---|
| Origin | Germany |
| Model | AL8 |
| Plasma Source | 2.45 GHz microwave, 600 W |
| Chamber Volume | 18 L (250 × 250 × 290 mm, aluminum) |
| External Dimensions | 530 × 600 × 550 mm |
| Gas Delivery | 1 standard mass flow-controlled line (MKS digital controller) |
| Vacuum Door | Hinged with UV- and microwave-shielded viewport |
| Control Interface | 7" GUI touchscreen, Windows CE OS |
| Optional | Dry pump system, tri-color status tower light, up to 4 gas lines, ECR-enhanced plasma source, motorized rotating stage (Ø200 mm, variable speed) |
| Brand | Alpha Plasma |
|---|---|
| Origin | Germany |
| Model | Q150, Q235, Q240, Q310 |
| Type | Microwave-excited Capacitively Coupled Plasma (CCP) Resist Stripping System |
| Application Domain | Semiconductor Front-End-of-Line (FEOL) & Back-End-of-Line (BEOL) Process Cleaning |
| Compliance | CE-marked, SEMI S2-0216 Certified, ISO 9001:2015 Manufactured |
| Footprint Options | Benchtop (Q150), Semi-automated Loadlock (Q235/Q240), Full-automated Cluster Tool Integration Capable (Q310) |
| Brand | Alpha Plasma |
|---|---|
| Origin | Germany |
| Model | Q235/Q240 |
| Plasma Source | 2.45 GHz microwave, 600 W |
| Chamber Material | Quartz |
| Chamber Dimensions | Ø235 mm × 260 mm L |
| Maximum Wafer Size | 200 mm (8") |
| Footprint | 460 mm × 590 mm × 550 mm H |
| Gas Inlets | Standard 2-channel with digital MKS mass flow controllers |
| Chamber Door | Drawer-type with UV- and microwave-shielded viewport |
| Human-Machine Interface | 7" resistive touchscreen GUI running Windows CE |
| Optional | Dry pump package (with foreline trap & vibration isolation), Faraday cage, quartz boat, tri-color status beacon, up to 4 gas lines, export-grade crating and freight logistics |
| Brand | Alpha Plasma |
|---|---|
| Origin | Germany |
| Model | Q235 (Q-Series) |
| Type | Benchtop Microwave Plasma Asher/Stripper |
| Application Domain | Semiconductor Fabrication, MEMS Processing, R&D Cleanroom Environments |
| Compliance | CE-marked, ISO 14644-1 Class 5 compatible installation, ESD-safe chamber design |
| Power Supply | 230 V AC, 50/60 Hz, 16 A |
| Microwave Frequency | 2.45 GHz |
| Max Chamber Volume | 12 L |
| Process Gas Compatibility | O₂, CF₄, SF₆, Ar/O₂ mixtures |
| Vacuum System | Integrated dry scroll pump (base pressure < 5 × 10⁻² mbar) |
| RF/Plasma Monitoring | Real-time forward/reflected power metering with auto-tuning impedance matching network |
| Brand | ELIONIX INC. |
|---|---|
| Origin | Japan |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | ELS-F150 |
| Price Range | USD 1.6–2.7 million (FOB Japan) |
| Brand | Alpha Plasma |
|---|---|
| Origin | Germany |
| Model | AL76 |
| Plasma Source | 2.45 GHz microwave, 1200 W |
| Chamber Volume | 76 L (400 × 400 × 490 mm, aluminum) |
| External Dimensions | 1050 × 800 × 2020 mm (incl. signal tower) |
| Gas Inlets | 3 standard mass flow-controlled lines (MKS digital controllers) |
| Door Type | Dual-mode hinged/drawer with UV- and microwave-shielded viewport |
| Control Interface | 10.4" resistive touchscreen, Windows CE OS |
| Optional | Dry pump package, tri-color signal tower, up to 4 gas lines, φ350 mm motorized rotating stage, ECR enhancement module |
| Brand | SCIL |
|---|---|
| Origin | Netherlands |
| Model | LabSCIL |
| Wafer Size | Up to 8-inch (200 mm) |
| Alignment Accuracy | < 1 µm |
| Imprint Technology | Low-Force Soft-Mold Substrate-Conformal Nanoimprint |
| Compatible Resists | Thermal Sol-Gel, UV Sol-Gel, UV Organic |
| Wafer Thickness Range | 0.3–2.5 mm |
| Footprint (W×L×H) | 1.8 × 1.4 × 2.2 m |
| Resist Application | External Spin-Coater Required |
| Compliance | Designed for ISO Class 5–7 cleanroom integration |
| Software | SCIL Control Suite with Audit Trail & Parameter Logging |
| Brand | SAMCO |
|---|---|
| Origin | Japan |
| Model | UV-300H |
| Maximum Sample Diameter | Ø800 mm (8-inch) |
| Operating Environment | Ambient Atmospheric Pressure |
| Heating Stage Temperature Range | Room Temperature to 150 °C |
| Safety Features | Interlocked Lid, Ozone Catalyst Scrubber, N₂ Purge Cycle, Thermal Fuse Protection, Emergency Stop |
| Compliance | Designed for ISO Class 5–7 Cleanroom Integration |
| Brand | Makeway |
|---|---|
| Origin | USA |
| Model | MKW-280 |
| Mask Size | 5 in |
| Wafer/Substrate Size | 5 in |
| Alignment Accuracy | 1 µm (Vacuum Contact), 1.5 µm (Hard Contact), 3 µm (Soft Contact), 5 µm (Proximity Mode) |
| UV Source | 350 W, 365 nm, uniformity ±3%, irradiance 30 mW/cm² |
| Exposure Time Range | 0.1–999 s |
| Chuck Motion | Manual X/Y/Z/θ with wedge compensation leveling |
| Microscopy | Dual CCD-based system, 80×–400× standard, up to 1000× with optional lenses, working distance 50–150 mm |
| Display | 20" LCD monitor |
| Contact Modes | Vacuum contact (adjustable force), hard contact, soft contact, proximity (gap adjustable) |
| Power Supply | 220 V, single-phase, 15 A |
| Optional | Deep UV source, IR alignment mode, custom substrate chucks |
| Brand | NILT |
|---|---|
| Origin | Denmark |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | CNI V4.0 PV |
| Pricing | Upon Request |
| Imprint Area | Up to Ø210 mm (8″) |
| Chamber Height | 20 mm |
| Thermal NIL Max Temp | 200 °C (optional 250 °C module) |
| UV-NIL Wavelength | 365 nm (optional 405 nm module) |
| Vacuum Level | ≤0.1 mbar |
| Maximum Imprint Pressure | 11 bar |
| Control Interface | Laptop-based with dedicated software |
| Automation Level | Fully automated process execution (manual stamp/substrate loading) |
| Form Factor | Benchtop, modular, plug-and-play |
| Brand | Makeway |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Authorized Distributor |
| Region of Origin | Domestic (China) |
| Model | MKW-320 |
| Price Range | USD 21,000 – 55,000 |
