| Brand | KJ GROUP |
|---|---|
| Origin | Liaoning, China |
| Model | HXQ-50 |
| Instrument Type | Hot Mounting Press |
| Power Supply | AC 220 V, 50 Hz |
| Rated Power | 1200 W |
| Temperature Range | 30–180 °C |
| Pressure Range | 10–2000 kPa |
| Holding Time | 1–900 min |
| Cooling Method | Water-cooled (auto-stop at ≤50 °C) |
| Mold Diameters | Ø25 / Ø30 / Ø40 / Ø50 mm |
| Max. Samples per Cycle | 2 |
| Dimensions (W×D×H) | 600 × 490 × 550 mm |
| Weight | 100 kg |
| Ambient Requirements | ≤1000 m altitude, 10–40 °C ambient, 45–65 %RH |
| Water Connection | Required (inlet & drain) |
| Ventilation | Mandatory |
| Brand | KJ GROUP |
|---|---|
| Origin | Liaoning, China |
| Model | UNIPOL-1200M |
| Dimensions (L×W×D) | 660 mm × 460 mm × 720 mm |
| Number of Grinding/Polishing Plates | 1 |
| Plate Diameter | 300 mm |
| Platen Speed | 50–500 rpm |
| Carrier Head Speed | 1–60 rpm |
| Applied Pressure Range | 0.15–0.4 MPa |
| Power Supply | AC 220 V, 50 Hz, 450 W |
| Weight | 80 kg |
| Standard Carrier Plate Diameter | Ø150 mm |
| Standard Specimen Holders | Ø25 mm (optional: Ø22/Ø30/Ø45 mm) |
